Norwesco 140 Gallon Plastic Containment Tray in Black

What a 140 gallon tray is for

Containment is sized to the thing on top of it. The common rule, written into many state and local requirements, is that a containment basin holds the full volume of the largest container inside it, sometimes with a margin, so this tray suits a tank or a pair of drums whose combined contents are comfortably under 140 gallons, on a footprint that fits inside 45 by 45 inches. A chemical feed tank in a treatment room, a drum of cleaner or oil in a shop, a day tank beside a boiler and a small fertilizer tank in a barn are the usual jobs. The tray is square, so it goes in a corner or a single bay; where the arrangement is a row of containers, the longer tray linked below is the better shape. Confirm the volume rule with the authority that inspects your site before you buy, because the margin they require decides whether one container fits or two.

What to check before you buy

1. Footprint. The container's base, including feet or a pallet, must sit inside the tray with room to work round it. Measure the base, not the rated size.
2. Height. The tray adds 17 inches under whatever sits in it. Check the clearance to a shelf, a pipe or a ceiling, and the lift height of the forklift or the two people who set the container in.
3. The liquid. Polyethylene handles water, most fertilizers and many common chemicals; for anything aggressive, check it against the material before you order and ask us if it is not on the list. The tray is rated for liquids up to 1.5 times the weight of water.
4. Drain. An 8 inch opening is the only fitting. Nothing else comes installed; if you want a drain valve to empty rainwater from an outdoor tray, tell us and we quote a bulkhead fitting with it.
5. Drawing. Norwesco's drawing for this tray is linked under Technical Drawing on this page and gives the inside dimensions and the wall profile.

Setting it up

Put the tray on a flat, continuous floor; a tray that bridges a drain or a joint will crack under a full container. Set the container in the centre so the load is spread, and keep the tray clear of standing liquid: a basin that already holds rainwater has lost part of its capacity before the leak it was bought for. Outdoors, check it after storms and drain it. Indoors, look in it on every round, because a slow drip that fills a tray over a month is exactly the failure containment exists to catch.

The other size

For a row of containers or a single long tank, Norwesco makes the 360 gallon containment tray, a long rectangle rather than a square; its page carries its own dimensions.

Shipping and receiving

The tray ships LTL on a pallet, 48 by 45 by 17 inches and 75 lb packed, under NMFC 156600-03, from Norwesco's Fairfield, Texas or Shawnee, Oklahoma plant, whichever is nearer. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. If you are ordering it under a tank, put both on the same order so they arrive together. At the tailgate, check 42771 against the bill of lading and look at the corners and the rim for transit damage, then fill it with a few inches of water on the floor where it will live, to prove it holds before anything sits in it.

Questions before you order? Call 866-418-1777.
