Chem-Tainer 75 Gallon Vertical Storage Tank

The Chem-Tainer 75 Gallon Vertical Storage Tank (SKU TC2349IC-NAT) is a compact polyethylene vertical tank built for water and general storage where floor space is tight. It stands 49 inches tall on a 23 x 23 inch footprint, so it tucks into a corner of a pump house, utility room, or equipment skid while still holding a useful 75 gallons. The natural white polyethylene construction suits water and general storage duty, and the narrow 23-inch width is the reason it fits where a wider tank cannot go.

Will it work for your job?

This is a 75 gallon vertical storage tank molded in polyethylene with a 1.5 specific gravity rating, meaning the wall is built to carry contents up to 1.5 times the weight of water. Filled with water, the tank and contents weigh about 626 pounds; at its full 1.5 SG rating it is engineered to hold up to 938 pounds of contents. Plan your pad and support for the heavier of those two numbers if you ever store anything denser than water. Overall dimensions are 49 inches high by 23 inches wide by 23 inches deep, and the 23.0 x 23.0 footprint makes it easy to size a base. At 23 inches wide the tank body clears a standard doorway on width, but check your overhead clearance and any top dome or lid height before you move it through a low opening. Use our Tank Sizing Calculator and Tank Sizing Guide if you are still matching capacity to your draw-down or reserve requirements.

Where it fits

People reach for a tank this size as a compact vertical tank for general water storage, day-tank duty, rainwater catchment overflow, or a small reserve feeding a pump. The 23-inch footprint is what makes it work in tight mechanical rooms and against walls where a wider tank cannot go. If you are sizing a larger reserve or comparing brands, the guide on Snyder vs Norwesco vs Chem-Tainer vertical storage tanks walks through how these lines differ, and our concrete pad sizing framework covers building a proper base under an above-ground poly tank.

The mistake to avoid

The 1.5 SG rating is a structural ceiling, not a chemical clearance. It tells you the wall can carry a denser liquid, but it does not by itself qualify this tank for any specific chemical. Fitting and lid configuration is not published in our data for this SKU, so confirm the inlet, outlet, and lid layout against the technical drawing on this page before you order rather than assuming a factory port location. If your contents are anything other than water, verify the polyethylene resin and the gasket and O-ring materials against the OEM chemical-resistance chart, concentration- and temperature-specific, before you fill.

This tank ships LTL freight from the nearest Chem-Tainer plant, either Marked Tree, AR or Hanford, CA, and the live ZIP quote picks whichever plant is closest to you, so your coast matters for the final rate. Get your number in seconds with the Freight Cost Estimator, or call 866-418-1777 and we will quote it for you.
