100 gallons with a 2 inch outlet, under three and a half feet, ships by UPS
The Snyder 1012700W94303 is a white polyethylene vertical liquid storage tank, 30 inches across and 41 inches tall, holding 100 gallons at 43 pounds. It carries the same 1.9 specific gravity wall as the big chemical tanks, rated for 1,585 pounds of contents against 834 for water, it comes with a 2 inch outlet already in the wall, and at this size it goes out by UPS rather than on a truck. An 18 inch lid on top, wide enough for a hand and a brush, and a 30 inch base that stands under a bench without a strap.
Need the certification on file? Add the 100 gallon tank to your cart above with freight quoted to your ZIP, or call 866-418-1777 and the paperwork ships with the tank.
Two drums in one tank, with the outlet already in
A hundred gallons is two drums, and a tank with the outlet already installed goes to work the day it arrives: thread a valve into the 2 inch port, set it in a tray, fill it. The wall is sized for a liquid nearly twice as dense as water under ASTM D1998, the standard rotationally molded polyethylene tanks are specified to; the HDPE tank wall thickness guide explains the sizing logic and why the vapor headspace is where a wall fails first. Full, it puts 1,585 pounds on a 30 inch circle at the rating, which any floor built for a drum carries. The tank sizing calculator sizes a day tank to feed rate and shift length, and the tank sizing guide covers the reserve.
The W94303 pair, and the sizes beside them
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1012700W94303 (this tank, 2 inch outlet) | 100 | 30 x 41 in | 43 lb |
| 1540200W94303 | 120 | 32 x 41 in | 50 lb |
| 5690100N45 (ASTM certified) | 90 | 34 x 41 in | 50 lb |
The 1540200W94303 is the same build at 120 gallons, 2 inches wider on the same 41 inch height, for a site that wants a little more between fills. The 5690100N45 is the certified 90 gallon tank at this height on a 34 inch base, for a job that needs the paper on file.
Pad already poured? Send its size to 866-418-1777 or in a quote request and we will match a row to it, freight to your ZIP included.
Outlet and manway
- Outlet: 2 inch, installed; thread in a valve and run a flexible line to the pump suction, with the valve supported off the floor.
- Access: 18 inch lid; filled by hand, wand or transfer pump, and vented outside on anything that fumes.
The white wall shows the level through it, which is the point of a day tank: the operator sees the charge go down over the shift. A float switch for low level protects the dosing pump, and a calibration column on the suction lets the feed rate be checked by eye. Keep the lid closed against vapor loss, and set the tank in a spill tray; a 30 inch tank fits any of them. Label it so the fire inspector and the workplace inspector read the same thing.
Who buys this tank
A day tank for hypochlorite, acid, caustic or inhibitor at a dosing skid, polymer make-down, brine for a softener, rinse water at a wash station, and a buffer for a well pump. One liquid per tank, labeled.
Delivery day
The 1012700W94303 ships by UPS (NMFC 156600) in a carton, so the freight cost estimator shows a parcel rate for your ZIP rather than a truck, and the listed price is before freight. One person carries 43 pounds through any door. Fill it to the lid once, check the outlet fitting for a weep, and drain and dry before the chemical goes in. Keep the delivery paperwork with the tank; the serial number on the shell is what a warranty claim starts from.
Freight and documents
Ships from: Philippi, WV. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1012700W94303.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Snyder Industries 100 Gallon HDPE Vertical Liquid Storage Tank in White video (70 seconds) with dimensions, fittings and shipping notes.
