Norwesco 1500 Gallon Plastic Two Compartment Septic Tank with Gaskets, Tees, and 2 Manhole Covers - IAPMO Certified

Why two compartments and two manholes

At 1500 gallons this is the septic size for a larger house in most codes. In a single chamber tank, solids settle and scum floats in the same space the outlet draws from, and a surge can push solids toward the drainfield. A two compartment tank takes the raw flow in the first chamber, lets most of the solids drop there, and passes calmer water into the second chamber before it reaches the outlet tee; the drainfield lasts longer for it. A manhole over each chamber means the pumper can clean both sides without guessing where the baffle is, and many codes now ask for exactly that. Our comparison of single compartment and two compartment septic tanks covers when the second chamber is required and when it is simply the better choice. On approvals, take Norwesco's IAPMO listing and the drawing to the permit desk, and tell us your state so we can confirm this part number is the one listed there; our note on Norwesco IAPMO and CSA B66 septic tank approvals explains what the listing covers.

What comes with it, and what to check

1. Tees and gaskets. A 4 inch gasketed PVC tee assembly at the inlet and at the outlet, with the gaskets, for 4 inch drain pipe. The gaskets seal the pipe where it passes through the wall; keep them clean and dry until the plumber arrives.
2. Manholes. Two 20 inch gasketed manways, both covers included. Gasketed lids keep groundwater out and septic gas in. Ask us about risers if the tank will sit deep enough that the lids need bringing up to grade.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the baffle wall position, the invert heights of the inlet and outlet and the spacing of the two manholes for laying out the hole and the risers.

Sizes nearby

At the same capacity, the 1500 gallon two compartment septic tank 41760 is the version without the gasket and cover kit, and the 1500 gallon one compartment septic tank with two manholes and the 1500 gallon Norwesco septic tank 41761 are the single chamber versions. One size down is the 1250 gallon one compartment septic tank. For water rather than waste, the 2000 gallon underground cistern tank is the buried storage tank. The tank sizing calculator and tank sizing guide cover sizing by bedrooms and daily flow.

Shipping, receiving and setting

The tank ships LTL from the nearest of Norwesco's plants at Griffin, Georgia; Lancaster, Ohio; Owego, New York; Shawnee, Oklahoma; St. Bonifacius, Minnesota; Tooele, Utah; or Washougal, Washington, 135 by 55 by 70 inches on the truck at 480 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. Have a machine to lift it. At the tailgate, check 44480 on the bill of lading against the moulded number, count both manhole covers and both tee assemblies, and walk the shell before you sign. Set it on the bedding Norwesco's installation instructions call for, and fill both compartments with water as you backfill so the walls and the baffle stay in shape; 1500 gallons of water weighs 12510 lb, and that water is what holds the tank round while the backfill goes in. Keep vehicles off the ground above it.

Questions before you order? Call 866-418-1777 with the permit in hand.
