Enduraplas TLV00450DG — Complete Reference
The Enduraplas TLV00450DG is a 450 Gallons vertical water tank in dark green, molded from polyethylene. Vertical above-ground potable water tank at the small-to-mid range in the Enduraplas lineup.
This page is the complete reference for the TLV00450DG: specs, compatible accessories, installation, freight, and warranty. Every number is sourced from the Enduraplas 2024 specification documents.
At-a-Glance
| Manufacturer Part Number | TLV00450DG |
| Brand | Enduraplas |
| Product Class | Vertical Water Tank |
| Capacity | 450 Gallons |
| Material | Polyethylene |
| Color | Dark Green |
| Diameter | 40" |
| Lid / Manway | 16" Threaded Vented Manway |
| Outlet | 2" PP Female NPT Bulkhead Fitting |
| Specific Gravity Rating | 1.1 |
| Shipping Weight | 130 lb |
| Certifications | FDA Approved |
| Warranty | 10-year limited warranty on vertical storage tanks |
| Freight Class | LTL |
Typical Applications
- Above-ground potable water storage (FDA-rated resin required)
- Emergency / disaster reserve water
- Livestock drinking water with gravity-feed to troughs
Installation Checklist
- Install on a flat, level pad extending 6 inches beyond the tank footprint
- Fit a top-vent to prevent vacuum collapse on high-flow draw
- Size overflow fitting at 1.25x the fill rate
- Verify SG rating matches your stored liquid BEFORE filling
Shipping & Freight
Ships LTL on a pallet. Residential deliveries need liftgate service. Call with your ZIP for exact freight.
Warranty & Certifications
10-year limited warranty on vertical storage tanks. Keep your One Source Plastics order confirmation — it's the warranty-claim trigger. Certifications on file: FDA Approved.
When This Product Is the Wrong Choice
- Storing petroleum or solvents — HDPE permeation is too high for diesel, motor oil, or hydrocarbons
- Pressurized service — these are atmospheric-vent-only tanks
Cross-Reference
| Supplier | Their SKU |
|---|---|
| One Source Plastics | TLV00450DG |
| Enduraplas | TLV00450DG |
FAQ
Is the Enduraplas TLV00450DG in stock?
Stock is split across manufacturer warehouses. We pull current inventory when you add to cart; if regional stock is short you'll see a ship-date estimate before checkout.
How fast does the TLV00450DG ship?
In-stock units typically ship within 3 business days of order confirmation. Out-of-stock units build on a 2-6 week cycle depending on the manufacturer. Call 866-418-1777 for a firm date.
Does the TLV00450DG include fittings?
The base tank ships with the manufacturer's standard fitting package. Upgraded bulkheads, flex connectors, or threaded outlets are separate line items — our team confirms fitment before shipping.
What warranty applies to this tank?
10-year limited warranty on vertical storage tanks. Keep your order confirmation — it's the claim trigger.
Can I download the technical drawing?
Yes. The branded View Technical Drawing button above your purchase links to the manufacturer's engineering PDF. Also appears in the Additional Information tab.
Questions about fitment, freight, or chemistry?
Our team has the Enduraplas catalog in front of them. Call 866-418-1777 or request a quote with MPN TLV00450DG ready.
Sources: Enduraplas 2024 specification documents. Specs verified against manufacturer-issued engineering drawings. Price and freight subject to change — see current listing above.
