The Snyder Industries 110 Gallon Heavy Duty Cone Bottom Mixing Tank (SKU 6070000N51) is a black cone bottom tank molded in high density linear polyethylene and rated to a 1.9 specific gravity. That heavy-duty wall schedule is what separates a true chemical-service mixing tank from a light-duty water vessel, and the practical read is simple: the 1.9 rating spans the full chemical list below, so you have density headroom for even the dense acids and salts you are likely to batch. It holds 110 gallons, stands 46 inches tall, and sits on a 30 by 30 inch footprint, so it drops into a tight mixing station or feed skid without sprawling. The cone bottom drains fully, which is what you want when you are batching, dosing, or flushing between chemistries rather than letting solids settle in a flat sump.
Will it work for your application?
Sizing is the part buyers get wrong, so run the real numbers. Filled with water this tank carries roughly 917 lbs; at its maximum rated 1.9 specific gravity contents it carries up to 1,743 lbs. That spread matters because a cone bottom tank does not stand on its own — it needs a stand or basket, and the stand has to be rated for the heavier 1,743 lb figure if you are running a dense chemical, not the water number. Plug your exact fluid into the Tank Sizing Calculator and read the Tank Sizing Guide before you commit to a frame. For matching this tank to a stand, the Cone Bottom Tank Stand Compatibility Matrix covers Norwesco, Snyder, and Enduraplas frames directly. One more thing to settle before you order: this tank's outlet and fitting package is configured to order, not fixed — confirm bulkhead size, fitting material, and gasket against your chemistry below or by calling 866-418-1777.
Chemical compatibility
This is an HDLPE tank rated to 1.9 specific gravity. The resin and SG rating govern what you can safely store, and the fitting and gasket materials have to match the chemistry — a tank that resists an acid is useless if the gasket on its outlet does not. The pattern in the list below is worth learning before you spec: strong oxidizers and aggressive acids (hydrochloric, sulfuric, hydrogen peroxide, phosphoric, hydrofluoric, sodium hypochlorite) call for Viton; most salts, bases, and glycols run EPDM; peracetic acid is the outlier needing Aflas; and a few service items (DEF, peracetic acid, propylene glycol, zinc orthophosphate) call for 316SS rather than PVC or PP. Always confirm against the OEM chemical-resistance chart for your specific concentration and temperature, since both shift the rating. The following are compatible with this HDLPE tank at the listed concentrations, with the recommended fitting and gasket materials:
- Acetic Acid at 60% — PP/PVC fittings, EPDM gasket
- Aluminum Sulfate at 50% — PVC fittings, EPDM gasket
- Calcium Chloride at 40% — PVC fittings, EPDM gasket
- DEF at 32.5% — 316SS fittings, EPDM gasket
- Ethylene Glycol at 100% — PVC fittings, EPDM gasket
- Ferric Chloride at 50% — PVC fittings, EPDM gasket
- Ferric Sulfate at 60% — PVC fittings, EPDM gasket
- Ferrous Sulfate at 20% — PVC fittings, EPDM gasket
- Hydrochloric Acid at 37% — PVC fittings, Viton gasket
- Hydrofluoric Acid at 48% — PP/PVC fittings, Viton gasket
- Hydrofluosilicic Acid at 26% — PP/PVC fittings, Viton gasket
- Hydrogen Peroxide at 50% — PVC fittings, Viton gasket
- Magnesium Chloride at 30% — PVC fittings, EPDM gasket
- Peracetic Acid at 30% — 316SS fittings, Aflas gasket
- Phosphoric Acid at 85% — PVC fittings, Viton gasket
- Polyaluminum Chloride — PVC fittings, EPDM gasket
- Potassium Carbonate at 50% — PVC fittings, EPDM gasket
- Potassium Hydroxide at saturated concentration — PVC fittings, EPDM gasket
- Propylene Glycol — PP/316SS fittings, EPDM gasket
- Sodium Bisulfate — PVC/PP fittings, EPDM gasket
- Sodium Bisulfite — PVC/PP fittings, EPDM gasket
- Sodium Carbonate at 30% — PVC fittings, EPDM gasket
- Sodium Hypochlorite at under 16.5% — PVC fittings, Viton gasket
- Sodium Thiosulfate at 40% — PVC fittings, EPDM gasket
- Sulfuric Acid at 98% — CPVC fittings, Viton gasket
- Urea Solution at 50% — PP/PVC fittings, EPDM gasket
- Zinc Orthophosphate — PP/316SS fittings, EPDM gasket
- Ozonated Water up to 10 PPM — PVC fittings, EPDM gasket (no dedicated reference page yet; verify directly, since this is a narrow concentration window)
Browse the full Chemical Compatibility Database to verify your exact chemistry, concentration, and temperature before ordering. The single most common mistake on a chem-service cone tank is matching the tank resin and SG correctly but then specifying the wrong gasket — note how the acids above call for Viton rather than EPDM. Get the gasket wrong and the outlet leaks long before the tank does.
Freight and ordering
This tank ships LTL freight from the Snyder plant in Lincoln, NE, quoted live to your ZIP — the list price here does not include freight. Get your exact number with the Freight Cost Estimator or call us at 866-418-1777. If you are pairing this tank with secondary containment, the Snyder Captor Plus 110% Containment vs UL-142 / SPCC comparison and the 110% vs 125% containment volume math by jurisdiction will help you spec a compliant basin, and the 110 Gallon Full Drain Cone Bottom Inductor Tank buyer's guide walks through the full setup.
