Snyder Industries 360 Gallon Cylindrical Gravity Feed Tank System

Where it goes

Head is everything on a gravity feed. Measure the height of the outlet above the point of use before the pad is poured, because a tank set low or on a soft, settling base is a tank that works slowly and then stops working well. The 52.3 by 65 inch footprint wants flat, continuous, level support across the whole base, not two bearers with the middle spanning air; 3,002 lb of water stands on it once it is full, and a gravity system cares about level in a way a pumped one does not, so take the time to get it right rather than shimming a corner. Where a pad has to be poured or an existing slab checked, our guide to concrete pad sizing for above ground polyethylene tanks covers the base. Check the 83.1 inch height against the door, the shelter or the canopy it is going under, measured with the pallet still beneath it. Size the volume to your real draw and refill interval in the tank sizing calculator, and take the headspace from the tank sizing guide.

Who buys it

Yard and depot dispensing points, farm and ranch supply, fleet and equipment shops, remote or seasonal sites with no power at the tank, and any operation that wants a simple, quiet supply with one thing to go wrong instead of five. The trade is that everything between the tank and the point of use is yours or your installer's to specify, so bring the duty, the draw rate and the height you have available and we will talk about the arrangement rather than guess at it. Check the liquid against the resin in our chemical compatibility guide before you order, and keep the contents under 120 F.

Openings and fittings

1. Lid. An 18 inch lid on top, above head height for most people standing beside the tank, so give whoever fills it somewhere safe to stand. Keep the hose end below the rim and the lid closed between fills. The lid is not described as vented; anything drawing the tank down needs an air path, so settle the venting with the order.
2. Outlet and dispensing valve. Not stated on this listing. Tell us how the liquid is meant to leave and at what height, and we will confirm what this part carries before it ships.
3. Drawing. Snyder's drawing for this system is linked under Technical Drawing on this page.

Shipping and receiving

The system ships LTL from Snyder's plant in Marked Tree, Arkansas, 53 by 66 by 84 inches on the pallet at 280 lb: an ordinary freight booking with a forklift or a pallet jack at the far end. The listed price is before freight; the freight cost estimator gives the cost to your ZIP. Lift from under the base, never by the lid, and check the door height and the canopy clearance with the pallet still under it. At the tailgate, check the part number against 5760100N97208 on the bill of lading and look over the lid and the base for transit damage. Set it on the finished pad, level it properly, fill it with water and hold the 3,002 lb load while you read the base, the opening and the pad, then drain and dry it before the working liquid goes in. Write the outlet height above the point of use on the site plan the day it is set; that one measurement explains every flow question anyone asks afterwards.
