65 gallons in a two foot circle, rated for 1.9 specific gravity
The Snyder 1550000C26 is a natural white polyethylene vertical storage tank, 24 inches across and 46 inches tall, holding 65 gallons. Its wall is rated for a specific gravity of 1.9, or 1,030 pounds of contents against 542 for water, which makes this the small tank for the dense liquids: a day tank for a chemical feed pump, a mix tank at a lab bench scale, a brine or a coagulant supply where a tote is too much and a drum is the wrong shape. A 3/4 inch polypropylene female NPT bulkhead outlet, an 8 inch threaded, vented lid, a 3 year warranty, and freight at class 175 from Lincoln, Nebraska.
Ready for the pad? Quote freight to your ZIP, add the 65 gallon tank to your cart above, and 866-418-1777 will confirm the truck and the unload.
A day tank, sized for a week
A chemical feed pump draws a few gallons a day, and the tank behind it is sized to the delivery interval, not the flow: 65 gallons is a week or more of feed on most metering duties, small enough to carry in on a hand truck, tall enough to keep the pump's suction flooded to the last inches. The 1.9 wall means it takes the liquids a water-rated jug will not, and the translucent white wall shows the level through it in daylight, which on a day tank is the whole gauge. Full at the rating it puts 1,030 pounds on a 24 inch circle: a level slab or a curbed containment pad per the concrete pad sizing guide, inside a berm or a spill tray when the liquid is a regulated chemical. The tank sizing calculator turns feed rate and delivery interval into a volume, and the tank sizing guide covers the reserve to keep in the bottom.
The small heavy-duty verticals, 60 to 70 gallons
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1550000C26 (this tank, 1.9 SG) | 65 | 24 x 46 in | 85 lb |
| 1550000N51 | 65 | 23 x 46 in | 28 lb |
| 1550000N45 | 65 | 23 x 46 in | 28 lb |
| 5680000N42 (XLPE) | 60 | 26 x 40 in | 26 lb |
| 1007200C26 | 70 | 23 x 42 in | 30 lb |
The N51 and N45 are the same 65 gallon shape in the other resin grades, listed on the sheet at 28 pounds against this tank's 85; the sheet gives both figures and we print what it says. The 5680000N42 is the 60 gallon cross-linked tank for oxidizers, shorter and a little wider, and the 1007200C26 the 70 gallon at 42 inches.
Still deciding between these? Freight to your ZIP often settles it; the wider tanks ship differently. Or call 866-418-1777 and we will walk the table with you.
The 3/4 inch outlet and the 8 inch lid
- Outlet: 3/4 inch polypropylene female NPT bulkhead fitting, at the base; the size a metering pump's suction line wants, with a flexible connector to the pump and an isolation valve at the tank.
- Access: 8 inch threaded, vented lid, 46 inches up; wide enough for a suction lance or a float, a funnel or a drum pump's hose.
- Service limit: 120 F / 48 C.
On a day tank the outlet feeds the pump directly, so the isolation valve at the bulkhead is what lets the pump be serviced without draining the tank; mount the pump below the outlet so it primes by gravity. A low-level float or a weight on the suction lance stops the pump before it draws air. Keep the lid closed against vapor and evaporation, label the tank with the one chemical it holds, and set it in a spill tray where the floor drains to somewhere it should not.
Where a 65 gallon 1.9 tank works
The day tank on a coagulant or a polymer feed at a small water plant, the chlorine solution tank on a well site, the acid or caustic day tank at a boiler room, a brine tank for a softener where the standard brine tank is the wrong size, a bench mix tank in a lab, and the supply tank on a pilot skid. Not a water tank; a 65 gallon water tank is a cheaper wall.
Shipping a small tank from Lincoln
The 1550000C26 ships from Lincoln, Nebraska as LTL freight at class 175; the freight cost estimator quotes it to your ZIP, and the listed price is before freight. One person walks it in on a hand truck. Fill it with water to the lid once and look at the outlet fitting for a weep, then drain and dry before the chemical goes in; on a day tank the first fill is the only test the tank will ever get. Write the chemical and the date on the wall in paint marker. Write the outlet fitting size and material on the site plan; the replacement is ordered by those two words.
Freight and documents
Ships from: Lincoln, NE. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1550000C26.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
