1500 Gallon Plastic Water Storage Tank

Where the low 1500 goes

Buy this shape when the site has ground but not height, or when the tank has to be worked from the top without a ladder. Rainwater harvesting off a large roof, where the inlet comes in low from a first-flush diverter and the tank sits beside the building under the eave; a stock water reserve in open country where wind matters and a tall tank would be a sail; a nurse or fill tank beside a field where a sprayer fills through the manway; a household reserve behind a fence that the neighbours do not want to look at. At 60 inches tall the manway is at chest height, so filling from a hose, dropping a pump in and cleaning by hand are all done from the ground. The 93 inch base makes it the steadiest tank at this capacity, and the weight is spread over a wide circle, but there is a lot of it: full, the tank puts more than six tons on the ground, so the base must be flat, level, continuous, engineered and poured wider than the floor; the concrete pad sizing guide gives the framework. What you give up is head: with five feet of water over the outlet, a gravity line from this tank runs slowly, so plan on a pump for anything that needs flow. Run the overflow to daylight away from the pad so a full tank never washes out its own footing. Check the volume against your real draw and refill interval with the tank sizing calculator and set the reserve from the tank sizing guide. For a rural fire reserve, the fire water reservoir design guide explains how the volume is set.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. A 2 inch valve, camlock or hose adapter threads straight in. Support the valve and the first length of pipe on their own so the fitting carries water, not hardware.
2. Inlet. A 1-1/2 inch polypropylene female NPT bulkhead fitting for the fill line, a float valve or the overflow.
3. Manway. A 16 inch vented manway on top, at chest height on this tank: wide enough to fill from a hose or a pump, drop a float in, and get a hand and a brush inside to clean. The vent lets air in and out as the level changes; never plug it.
4. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the fitting positions and the manway location.

Sizes nearby

Close below it is the 1350 gallon dark green tank; close above it is the 1525 gallon dark green tank. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL at freight class 400 from Norwesco's Burnet, Texas plant, 93 by 93 by 60 inches on the truck at a ship weight of 215 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. A tank nearly eight feet across does not come off on a liftgate; plan on a forklift, a loader or three people and a clear drive, and tell us about the site when you order. At the tailgate, check the part number against 41506 on the bill of lading and look at the wall, the manway and both fittings for transit damage. Fill it with water the first time and hold it a day before it goes into service, watching the fittings and the base; the water fill acceptance test guide gives the method.

Questions before you order? Call 866-418-1777.
