The Bushman TC4000IW-GREEN is a 4,000-gallon vertical plastic water storage tank in green, built for high-volume bulk holding on farms, ranches, remote fire-water reservoirs, and industrial water-reuse trains. It stands 140 inches tall — 11 feet, 8 inches — over a 95-inch-diameter round base, so plan both the pad footprint and the overhead access for filling and gauging at nearly 12 feet. Dimensions on this listing are verified; see the technical drawing on this page for the full profile.
Will it work for your site?
At 4,000 gallons this is a serious water-column tank: a full fill of fresh water weighs roughly 33,360 pounds. That single number drives your whole install. The tank is 95 inches in diameter, so size the pad to clear that circle with overhang on every side — do not pour a pad tangent to the wall. The load has to land on a properly engineered foundation, not bare soil, or the base will settle unevenly and stress the tank wall. If you are sizing that foundation, walk through our concrete pad sizing framework before you pour, and confirm the volume you actually need with the Tank Sizing Calculator and Tank Sizing Guide so you are not paying to move and set a bulk water storage tank that is a size off.
Common uses and the mistake to avoid
This is a vertical bulk water storage tank — water hauling, irrigation supply, rainwater and grey-water aggregation, and stored fire-water reserve. If you are building a private fire-protection reserve, the sizing discipline differs from general storage; our guide on fire-water reservoir tank design covers NFPA 22 volume math and cold-climate freeze protection. For reuse setups feeding off rainwater, grey-water, or HVAC condensate, see our breakdown of water-reuse tank topology. The mistake to avoid is service creep: this is a water tank. If you plan to store a chemical or any fluid heavier than water, do not assume the wall is rated for it — a heavier fluid raises the hydrostatic load past what a standard water tank is built to carry, and you need a specific-gravity-rated tank instead. Call us at 866-418-1777 before you change the service and we will spec the right tank.
Fittings, start-up, and acceptance
Inlet, outlet, and lid are configured at order — call 866-418-1777 to spec the ports and access you need rather than assuming a fixed arrangement. On a new install, fill and hold the tank with water and monitor it before you put it into full service. A staged water-fill lets you watch the pad for settlement and every fitting for weeping while the load is still recoverable. Our hydrostatic test methodology lays out the fill discipline and hold-time math for accepting a tank this size.
This 4,000-gallon vertical water tank ships LTL freight, quoted live to your delivery ZIP — get your number in seconds with the Freight Cost Estimator, or call us at 866-418-1777 and we will walk the delivery and set details with you. Listed price is before freight.
