50 Gallon Vertical Liquid Storage Tank

A drum's footprint, a drum's volume, and a tank's fittings

Fifty gallons on an 18 inch circle is the volume of a drum on the footprint of a drum, with a proper bottom outlet and a vented lid instead of bungs. That is why it replaces drums: beside a chemical feed pump, at a wash station, as a mixing vessel for treatment solution, behind the cab of a utility truck, or as the working reserve for a piece of equipment. The height is the thing to plan around. At 53 inches the lid is chest high, so the fill wants a line and a coupling rather than a hose held up; the tank is easy to tip at 25 lb empty and carries several hundred pounds on an 18 inch circle when full, so strap it to a wall, rack or frame before the first fill; and the floor must carry the whole base, a solid deck or slab set level with nothing packed under one edge. If it stands outdoors on a pad, our concrete pad sizing guide for above ground polyethylene tanks applies at small scale. Before anything but water goes in, check the liquid in our chemical compatibility guide. Run 50 gallons against your real draw and refill interval in the tank sizing calculator, and take the reserve and freeboard advice from the tank sizing guide.

Openings and fittings

1. Outlet. A 3/4 inch polypropylene female NPT bulkhead fitting low in the wall. A ball valve or a pump suction threads straight into it; support the valve so the fitting carries liquid, not hardware.
2. Lid. A 5 inch threaded vented lid on top. It takes a hose or a funnel comfortably but not a hand, so plan on flushing rather than scrubbing to clean this tank. The vent lets air move as the level changes; never seal it.
3. Drawing. Norwesco's drawing for this tank is linked under Technical Drawing on this page and shows the outlet position.

Colours and sizes nearby

The same tank in black: the 50 gallon black vertical storage tank; the colour swatches above the price switch between the two. One size down on the same base, the 40 gallon heavy duty vertical storage tank; one size up, the 55 gallon vertical liquid storage tank, which is shorter and wider in the shoulder.

Shipping

This tank ships by LTL freight from the nearest of Norwesco's plants, 18 by 18 by 53 inches and 50 lb on the pallet. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote if the job needs paperwork. If it is going on the same job as a larger tank, put both on one order so they travel on one truck. Check the part number against 41865 on the bill of lading, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
