A 25 gallon black vertical tank for a corner, a cabinet or a cart
The Norwesco 25 gallon black vertical storage tank, part number 43937, is a small polyethylene tank 18 inches in diameter and 29 inches tall, weighing 15 lb empty. It is the size that goes where a drum will not: beside a boiler, under a bench, on a wash-down cart or in the corner of a greenhouse. It comes with a 3/4 inch polypropylene female NPT bulkhead fitting at the outlet and a 5 inch threaded vented lid on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 25 gallons of water weighs 208 lb. The resin is FDA compliant, Norwesco lists the tank as NSF 61, the service limit is 120 F, and Norwesco backs it with a 3 year warranty. Black keeps light out, which stops algae in stored water and protects light sensitive solutions.
Need it with a valve or a second tank? Call 866-418-1777 and we will put everything on one order, or get freight to your ZIP and add it to your cart above.
Where it goes
An 18 inch circle is a smaller footprint than a drum, and at 29 inches tall the lid sits below a standard bench top, so this tank fits inside cabinets and under counters where nothing else will. Typical duties are a day tank feeding a chemical pump, a rinse or make-up water tank on a cart, a reservoir for a small irrigation or misting system, and a holding tank in a lab or a wash bay. It needs a flat, continuous surface under the whole base; a flat bottomed tank carries its weight through whatever is under it, so sweep the spot first. On a new outdoor pad, our guide to concrete pad sizing for above ground polyethylene tanks covers the thinking, though at 208 lb full this tank will sit on any sound floor.
What goes in it
Water, fertilizer solution, cleaning solution and the treatment chemicals that polyethylene handles are the normal loads. Check anything stronger in our chemical compatibility guide before it goes in, and keep the contents at or below 120 F. Liquids heavier than 1.5 times water need a heavy duty tank. If you are not sure 25 gallons is enough, the tank sizing calculator and tank sizing guide walk through the choice.
Openings and fittings
- Outlet. A 3/4 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 3/4 inch ball valve, a hose barb or the suction line of a small pump threads straight in. Dry-fit the valve so the handle clears the tank before you tighten it.
- Lid. A 5 inch threaded vented lid on top: big enough to fill from a hose or a jug and to drop a small float or a suction tube in. Keep the vent clear so a pump can draw without pulling the walls in.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the exact outlet and lid positions.
Sizes nearby
Same tank in white, for liquids where you want to see the level through the wall: the 25 gallon vertical storage tank in white. One size down: the 22 gallon vertical storage tank. One size up, built for liquids heavier than water: the 40 gallon heavy duty vertical storage tank. The colour swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL at freight class 250 from the nearest of Norwesco's plants, 18 by 18 by 29 inches and 15 lb. Norwesco moulds this size at plants across the country, so the lane is usually short. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote. Two of these on one shipment cost little more than one, so if a second tank is in your plans, order them together. At the tailgate, check the part number against 43937, look at the bulkhead fitting for transit damage, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Sheldon, IA by UPS when ordered alone. Larger orders ship LTL from: Hanford, CA; Griffin, GA; Sheldon, IA; St. Bonifacius, MN; Owego, NY; Washington Court House, OH; Shawnee, OK; Fairfield, TX; Tooele, UT; Washougal, WA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 43937.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
