200 gallons on a 36 inch base, rated for 1.9 specific gravity
The Snyder 1008000C26 is a natural white polyethylene vertical storage tank, 36 inches across and 53 inches tall, holding 200 gallons at 65 pounds. Its wall is rated for a specific gravity of 1.9, or 3,169 pounds of contents against 1,668 for water, so it holds concentrated acid, ferric and the heavy brines at strength, and at 200 gallons it is the tank that replaces a tote: the same volume, but with a proper 18 inch threaded, vented manway, a real base outlet, and a wall that is not meant to be thrown away. A 2 inch polypropylene female NPT bulkhead outlet, a 3 year warranty, and freight at class 300 from Merced, California.
Ready to price it? The listed price is before freight; quote freight to your ZIP in a few seconds, then add to cart above or call 866-418-1777.
The tote replacement
A plant that takes chemical by the tote is paying for a container every delivery and handling a cage every time; a 200 gallon tank on a pad takes the same load pumped over from the tote and keeps the fitting, the valve and the level gauge in one place, permanently. The 1.9 wall covers the dense chemicals a tote does, and the white wall shows the level through it in daylight. Full at the rating it puts 3,169 pounds on a 36 inch circle: a level slab per the concrete pad sizing guide, inside a berm sized to the tank when the liquid is a regulated chemical, with the empty tank strapped because a tall thin tank catches wind. The tank sizing calculator turns feed rate and delivery interval into a volume, and the tank sizing guide covers the reserve; on a tank this size the reserve is what keeps a pump wet between deliveries.
Grades on the 36 x 53 inch tank, and the next sizes up
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1008000C26 (this tank, 1.9 SG) | 200 | 36 x 53 in | 65 lb |
| 1008000C34 | 200 | 36 x 53 in | 65 lb |
| 1008000N42 (XLPE) | 200 | 36 x 53 in | 65 lb |
| 1008000N48 | 200 | 36 x 53 in | 65 lb |
| 1012900C26 | 210 | 36 x 55 in | 65 lb |
| 1540400N42 (XLPE, low) | 190 | 42 x 47 in | 60 lb |
The C34 is this tank's twin in the other general grade; the N42 is the cross-linked one for oxidizers like hypochlorite, and the N48 the other chemical grade in the same shell. The 1012900C26 is the 210 two inches taller on this base, and the 1540400N42 lays 190 gallons down to 47 inches on a 42 inch base in the cross-linked resin.
Want us to check the fit? Send the site dimensions to 866-418-1777 or through a written quote request and we will confirm the tank, the pad and the freight.
Outlet, manway, limit
- Outlet: 2 inch polypropylene female NPT bulkhead fitting, at the base; a flexible connector to hard pipe, the valve supported off the pad, and a reducer to the pump's suction size at the pump, not at the tank.
- Access: 18 inch threaded, vented manway, 53 inches up, opened from the floor; fill from a tote or a drum pump through a dip tube, and vent outside on anything that fumes.
- Service limit: 120 F / 48 C.
A 2 inch outlet on a 200 gallon tank is oversized on purpose: it drains the tank in minutes for a chemical change and never starves a pump. Mount the pump below the outlet so it primes by gravity, put a low-level float on it, and keep the manway closed against vapor loss. One chemical per tank, labeled, and a spill tray or a curb under it where the floor drains somewhere it should not.
Who buys a 200 gallon 1.9 tank
A well site's chlorine or acid feed, a boiler room's chemical supply, the coagulant tank at a small water plant, a cooling tower treatment skid, and a shop's brine or cleaner tank. It is not the tank for a fire reserve, which the fire-water reservoir design guide sizes in thousands of gallons, and where a reuse system needs a small dosing tank on the treatment stage, the industrial water reuse tank topology article shows where it sits in the train.
Freight from Merced and the first fill
The 1008000C26 ships from Merced, California as LTL freight at class 300; the freight cost estimator quotes it to your ZIP, and the listed price is before freight. One person carries 65 pounds; it rides a hand truck through a door on its side. Fill it with water to the manway once and look at the outlet fitting for a weep, then drain and dry before the chemical goes in, and start the log with the first delivery. A photo of the tank on its pad, full, on day one is worth keeping; it is the baseline every later inspection is compared against.
Freight and documents
Ships from: Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1008000C26.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Ready to order?
Add it to your cart at the top of this page, get LTL freight to your ZIP, request a written quote, or call 866-418-1777. The listed price is before freight.
