Norwesco 165 Gallon Black Vertical Storage Tank

Where a 165 gallon vertical tank goes

Among the small Norwesco verticals this is the one with a full 16 inch manway and a 2 inch outlet, so it suits liquids that have to be mixed, inspected or cleaned out rather than just stored: spray solution, liquid fertilizer, brine for a softener or a treatment plant, and rainwater that will carry roof debris if the diverter is skipped. At 31 inches across and 56 inches tall it stands under a normal ceiling and leaves working room in a pump house, a greenhouse headhouse or a shop corner. Full of water it weighs 1376 lb on a 31 inch circle, so it needs a flat, continuous, level base; a slab or a paving base rather than soil. Where wind or animals can reach it, strap it to a wall or post. Our guide to bearing surfaces under polyethylene tanks covers the pad. For roof water, read the piece on sizing a first flush diverter before you plumb the downspout in.

What goes in it

Water, liquid fertilizer and the treatment and cleaning chemicals that polyethylene handles are the normal loads. Check anything else in our chemical compatibility guide first, and ask us about anything that is not listed. Liquids heavier than 1.5 times water need a heavy duty tank, and nothing hotter than 120 F belongs in it. If it is a water reserve on a site that freezes, our piece on reservoir sizing on remote sites and freeze protection covers what keeps the water liquid. The tank sizing calculator and tank sizing guide confirm the volume before you order.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 2 inch valve, camlock or hose adapter threads straight into it, and it empties the tank quickly when you need to switch liquids. Support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
2. Manway. A 16 inch threaded vented manway on top: wide enough to fill from a hose or a pump, to drop a float or a suction line through, and to get a hand and a brush inside. The vent lets the tank breathe as the level changes.
3. Extra fittings. An overflow, a return or a second draw-off is a bulkhead fitting through the wall. Tell us before the order and we quote it with the tank. Dry-fit, then hand tight plus a quarter turn.
4. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the outlet height and the manway position.

Sizes nearby

The same tank in white, where you want to read the level through the wall: the 165 gallon white vertical tank. Built for heavier liquids, one step either side: the 160 gallon heavy duty vertical tank and the 175 gallon heavy duty vertical tank. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL at freight class 300 from the nearest of Norwesco's plants, which include Fairfield, Texas; Griffin, Georgia; Hanford, California; St. Bonifacius, Minnesota; Owego, New York and Washougal, Washington. On the pallet it is 31 by 31 by 56 inches and 54 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 40731 on the bill of lading, look over the wall and the fitting for transit damage, make sure the manway lid is on and turns freely, and fill the tank with water the first time so any problem shows up with something harmless in it.

Questions before you order? Call 866-418-1777.
