A 275 gallon crosslinked double wall tank for a contained chemical feed
Snyder part number 5740102N42 is a 275 gallon double wall tank moulded in natural white crosslinked linear polyethylene. An inner tank sits inside an outer containment shell, so the tank is its own secondary containment. It is 47 inches in diameter, 63 inches tall and weighs 200 lb empty, with an 18 inch threaded vented manway on top. The wall is rated for liquids up to 1.9 specific gravity, and the service limit is 140 F (60 C). 275 gallons of water weighs 2,294 lb; at the full 1.9 rating the contents can weigh 4,358 lb. Snyder backs it with a 3 year warranty.
Matching the tank to a chemical? Call 866-418-1777 with the liquid, its strength and its temperature, or get freight to your ZIP and add it to your cart above.
Where it goes
At 275 gallons this is a feed tank or a day tank: chemical dosing at a well or a treatment skid, a reserve beside a process line, a small contained store in a shop where a spill cannot reach a floor drain. The 1.9 rating covers liquids nearly twice the weight of water, and the 140 F limit leaves room for liquids that run warm. If what you store is close to water in weight, ask us about a lighter rated tank.
The manway at 63 inches is within reach from a step, so filling and inspection need no platform. The 47 inch body is too wide for a single door, so measure the way in. Set it on a flat, continuous pad that can carry about 4,358 lb at the full rating.
A contained tank holds less usable liquid than its nameplate once freeboard and expansion are allowed for; the Snyder double wall freeboard sizing guide works it out. A polyethylene wall works hardest in the vapour space above the liquid, and our headspace wall thickness guide explains where to look during inspections. For a water reserve on a rural site, the fire water reservoir design guide covers sizing and freeze protection. The tank sizing calculator and tank sizing guide match volume to use.
Openings, and what to confirm before you buy
- Manway. One 18 inch threaded vented manway on top. It is the fill point, the vent and your view inside; keep the vent open during fill and draw.
- Outlet. No outlet or fitting is listed on this product. Tell us the pipe size, the valve and the pump, and we will confirm with Snyder what this part number carries.
- The liquid. Look it up in our chemical compatibility guide and give us the concentration; gaskets and valves have to suit it too.
- The space between the walls. No leak detection is listed with the tank. Decide how you will check that space and log it. Snyder's drawing is linked under Technical Drawing on this page.
Other 275 gallon versions, and the sizes either side
Snyder's 275 gallon double wall size also comes as the 275 gallon HDPE black double wall tank 5740102N51, the 275 gallon XLPE black double wall tank 5740102N48 and the 275 gallon sulfuric acid double wall tank 5740102N30. Each page states its own rating. A step down is the 250 gallon XLPE double wall tank 5990502N42; a step up, the 360 gallon sulfuric acid double wall tank 5760102N30.
Shipping and receiving
The tank ships LTL at freight class 250 from Snyder's Marked Tree, Arkansas plant, 47 by 47 by 63 inches on a pallet at 200 lb. At the tailgate, check the bill of lading against 5740102N42, walk around the outer wall and look at the manway threads, and note any damage on the receipt before you sign. Fill it with water first on its finished pad, check the base and the manway seal, then drain and dry it before it goes into service.
Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
Freight and documents
Ships from: Marked Tree, AR. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5740102N42.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
