Snyder Industries 3500 Gallon Sulfuric Acid Captor Double Wall Tank

Where it goes

At 158 inches tall this tank goes where a taller acid tank will not: under a canopy, inside an existing chemical building, below a pipe rack or a service run. It still holds 3,500 gallons, a real bulk quantity for pH control at a water or wastewater plant, fertilizer and chemical blending, or process supply, with day tanks and metering pumps fed from it. The Captor's outer wall is the containment, so the room does not need a dike sized to hold the tank; our Captor walkthrough for SPCC compliance explains how it is credited in a spill plan.

Snyder publishes no acid strength against this part number, so tell us the concentration and the temperature and we will confirm the tank with Snyder before the order. For any other liquid, our chemical compatibility guide is the starting point. Keep the contents under 120 F. Do not plan on the full nameplate: the Captor freeboard sizing guide shows how much room a heavy liquid needs above the working level. Size against your usage with the tank sizing calculator and tank sizing guide.

What to check before you buy

1. Clear height. 158 inches is the tank alone. Add the fill line, the transmitter and room to open the manway, then measure the building.
2. Pad. Over twenty-seven tons at the full rating, on a 102 inch circle. That needs a designed slab, not an old yard surface; see our guide to concrete pad sizing for above ground polyethylene tanks.
3. Manway. An 18 inch threaded vented manway on top for filling, instruments and inspection.
4. Fittings. No factory outlet is listed. Tell us the connections your piping needs; on a Captor they pass through both walls and are installed at the factory.
5. Drawing. Snyder's drawing, linked under Technical Drawing on this page, shows the overall dimensions and manway position.

Other versions and sizes nearby

The 3,500 gallon Captor also comes in cross-linked polyethylene as 5600000N40 and 5600000N42, and in black as 5600000N46. In the acid line, the 3000 gallon sulfuric acid Captor is one size down and the 4000 gallon sulfuric acid double wall tank one size up.

Shipping and receiving

The tank ships from Snyder's Lincoln, Nebraska plant at 102 by 102 by 158 inches and 2500 lb, freight class 250. At that width the online estimator does not price it, so call 866-418-1777 for freight with the ZIP and your unloading plan. The listed price is before freight. Lift it with slings, never by the manway. At delivery, check the part number against 5600000N30 on the bill of lading, walk the outer wall for transit damage, and fill it with water first to prove the fittings before acid goes in.

Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP with the freight cost estimator, or call 866-418-1777. The listed price is before freight.
