Snyder Industries 6900 Gallon Open Top Containment Tank 1.9 S.G. (VOT)

Going up instead of out

This tank keeps a 120 inch footprint and gets its volume from height: just over twelve feet to the rim. That is the case for it on sites where the slab was poured years ago and the process has grown since. It also serves as a very large open vessel, a break tank or a reservoir; our guides on industrial water reuse tank layouts and fire water reservoir design for rural sites cover those uses.

Snyder names it a containment tank. If you are buying it to contain another tank, tell us the inner tank and what your rules require, and we will check the fit and the volume with Snyder before you order. We do not state a containment percentage for it here.

The height is also the cost. At more than twelve feet, nobody works over this rim from a step ladder. Plan a fixed platform with rails and a safe way up at the same time as the tank. No maximum temperature is listed with this part number, so if the contents run warm, ask us first.

What to check before you buy

1. The foundation. Close to 29 tons of water, and up to 109,337 lb at the 1.9 rating, sits on the full floor of the tank. That is a designed slab, not a paving job. Read our concrete pad sizing guide for above ground polyethylene tanks before anyone orders concrete.
2. Around the tank. Where trucks load or unload nearby, slope, curbs and sumps matter as much as the slab. Our loadout pad engineering guide covers it.
3. Fittings. No outlet or fitting is listed with this part number. Tell us what connections you need and where, and we will confirm them with Snyder.
4. Weight. The tank is listed at 1,900 lb empty, but the shipping weight entry repeats the 6,900 figure. Ask us to confirm the shipping weight before you book a crane or a forklift.
5. Drawing. Snyder's drawing for 5970000N45 is linked under Technical Drawing on this page.

A smaller open top

If 6900 gallons is more than you need, the 5800 gallon open top batch storage tank in white, 1.9 S.G., 5960000N42 is the next size down; check its own dimensions. The tank sizing calculator and tank sizing guide help settle the volume.

Shipping and receiving

The tank ships LTL from Snyder's plant in Lincoln, Nebraska. The shipping dimensions are listed as 146 by 120 by 120 inches, so it is set up to travel on its side, ten feet wide on the trailer. That is an oversize load; call us for the freight lane and the unloading plan. The listed price is before freight; the freight cost estimator is the place to start for your ZIP. Have lifting equipment ready to stand it upright on the slab. When it arrives, check 5970000N45 on the bill of lading, walk the full wall and rim for transit damage, and fill it with water to check any fittings before it goes into service.

Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
