Snyder Industries 110 Gallon HDPE Vertical Liquid Storage Tank with ASTM Certification

Squat, certified, plant-grade wall

A 33 inch base under 41 inches cannot tip, so this is the day tank that stands on the floor beside a dosing pump without a bracket, holding a week of chemical for a small feed. What it shares with the largest tanks in the same line is the wall, sized for a liquid nearly twice as dense as water and certified against ASTM D1998, the standard rotationally molded polyethylene tanks are specified to; the HDPE tank wall thickness guide explains the D1998 sizing logic and why the vapor headspace is where a wall fails first, at any size. Full, it puts 1,743 pounds on a 33 inch circle, which a slab or a paver pad supports; the concrete pad sizing guide covers a shared slab. The tank sizing calculator sizes a day tank to the pump's rate and the refill schedule, and the tank sizing guide covers the reserve, which at this size is refilled from a drum or a tote.

Snyder's 100 to 120 gallon verticals

The N42 is cross-linked polyethylene for hypochlorite and the other oxidizers, and the N48 and N51 are other linear grades, all at this tank's weight in the same shell. The 1012700N48 holds 100 gallons at the same height on a base 3 inches narrower, and the 1540200N51 holds 120 gallons 2 inches shorter on a base an inch narrower.

Settled on the 110 gallon tank? Freight to your ZIP and add to cart above; a written quote is one click away for the paperwork.

Fittings and access

• Access: 10 inch lid; filled by hose, drum pump or tote pump.
• Outlet: specify the bulkhead fitting for the chemical when ordering; a flexible line to the pump suction and a valve supported off the floor.
• Service limit: 120 F / 48 C.
• Listing: ASTM certification.

Put the dosing pump below the outlet, where it primes by gravity, with a union and a check valve in the suction line. A white 41 inch tank shows its level at a glance; a low-level float switch protects the pump. Keep the lid closed against vapor loss and the tank out of direct sun where the chemical is light-sensitive; a 33 inch tank fits a standard spill pallet.

Jobs it is bought for

Day tanks at small water systems and well houses, chemical feed skids, lab and pilot plants, brine for a small softener, and, with water in it, one cell of the small reserve the fire-water reservoir design guide describes. One chemical per tank, labeled, rinsed at every changeover.

What the carrier needs from you

The 8010000N45 ships palletized as LTL freight (NMFC 156600-02) at a class rate; the freight cost estimator gives the number for your ZIP; the price shown here is before freight. One person carries 45 pounds. Check the lid and the outlet fitting, fill it once with water to prove the seal, and keep the certification paperwork with the project file. Note the pad height and the outlet height on the site plan while the tape is out; the next pipe run will need both.
