A 120 gallon tank with a 3 inch outlet
The Snyder 1540200W94303 is a white polyethylene vertical liquid storage tank, 32 inches across and 41 inches tall, holding 120 gallons at 50 pounds. Its wall is rated for a specific gravity of 1.5, or 1,501 pounds of contents against 1,001 for water, the 18 inch manway is wide for a tank this size, and the 3 inch outlet is the unusual part: it empties the tank fast, for a batch that is dumped into a mixer or a sprayer in one go. It ships as standard LTL freight.
Want it on your site? Get LTL freight to your ZIP, add it to your cart above, or call 866-418-1777 and a tank specialist will confirm the fit.
Built to empty quickly
Most tanks this size carry a 1 or 2 inch outlet sized for a small pump; a 3 inch outlet drains 120 gallons by gravity in a couple of minutes, which is what a batch mix tank, a sprayer nurse tank or a wash-down reservoir wants. The 1.5 wall covers brine, fertilizer solution and coagulant as delivered as well as water, and a 32 inch base under 41 inches cannot tip. The 120 gallon vertical tank buyers guide compares the shapes at this volume across makers; the tank sizing calculator tells you whether 120 gallons covers the batch, and the tank sizing guide covers the reserve.
Snyder's 50 to 300 gallon verticals
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 1540200W94303 (this tank, 3 inch outlet) | 120 | 32 x 41 in | 50 lb |
| 1012700W94303 | 100 | 30 x 41 in | 43 lb |
| 1540700N45 (ASTM certified) | 50 | 23 x 38 in | 26 lb |
| 1011200N52 (doorway) | 300 | 35 x 82 in | 85 lb |
The 1012700W94303 is the 100 gallon step down at the same height on a base 2 inches narrower. The 1540700N45 is the certified 50 gallon tank for a pilot skid, and the 1011200N52 stands 300 gallons on a 35 inch base at 82 inches for a doorway.
Picked the 120 gallon tank? Add it to your cart above; freight is quoted to your ZIP before you pay anything.
Outlet and manway
- Outlet: 3 inch, at the base; a full-port valve and a short run of hard pipe, supported off the floor.
- Access: 18 inch manway, wide enough for a hand and a hose at once.
- Service limit: 120 F / 48 C.
A 3 inch valve on a 120 gallon tank is opened with the receiving vessel already under it, because the whole tank is on the floor in a couple of minutes if it is not. The white wall shows the level at a glance. On a sprayer trailer the tank is strapped through the manway ring and the outlet faces the pump; in a shop it stands on a bench or a low stand so the outlet clears the receiving vessel.
Who buys this tank
A batch mix tank for fertilizer or chemical that is dumped into a sprayer, a nurse tank on a trailer, a wash-down reservoir, a brine tank for a small softener, and a make-up tank in a shop. One liquid per tank, labeled, rinsed between batches.
Delivery day
The 1540200W94303 ships palletized as LTL freight (NMFC 156600-03) at a class rate; the freight cost estimator shows it for your ZIP, and the listed price is before freight. One person carries 50 pounds. Fill it to the manway once, hold it, and work the 3 inch valve before it goes into service. Keep the delivery paperwork with the tank; the serial number on the shell is what a warranty claim starts from.
Freight and documents
Ships from: Merced, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1540200W94303.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Snyder Industries 120 Gallon Plastic Vertical Liquid Storage Tank in White video (64 seconds) with dimensions, fittings and shipping notes.
