Snyder Industries 130 Gallon ASTM XLPE Black Heavy Duty Vertical Storage Tank

Bought by the crew that mixes and sprays

The duty first, because at 130 gallons the duty is the only thing that matters. This is the size a crew fills, uses and refills: a mix and transfer tank a spray or vegetation crew loads from, a chemical supply tank on a wash rack, a small plant's polymer or hypochlorite day tank sitting beside the metering pump, a shop's rinse or coolant reservoir, a barn tank for treated stock water or a nutrient blend. It is bought to be worked, and the shape reflects it: 49 inches puts the 8 inch lid at chest height on a man standing beside it, which means a hose goes in and a paddle comes out without a ladder, and 29 inches of footprint means it goes on a stand, a rack or the corner of a slab rather than in a dedicated space. The delivery is a pallet on an LTL trailer at 45 pounds, which is the lightest tank in this batch and the easiest one to receive; a forklift or two people with a liftgate handles it, and the tank is in service the same day if the unload was arranged in advance. What people get wrong on a tank this small is the standing surface, because it looks like something you can set down anywhere. Do not. The base bears on everything it touches and nothing else, so 1084 pounds of water on a tank straddling a pallet rail, a drain lip or a cracked slab edge concentrates on that line. A level stand or a flat pad sized the way the concrete pad sizing guide lays out is the fix, and it costs nothing on a tank this size. Where the liquid is regulated the tank sits inside containment sized to it. Check the number against how much the crew actually draws between refills in the tank sizing calculator, and take the reserve and warm weather freeboard from the tank sizing guide.

The 130s, and the 49 inch difference

Four tanks here hold 130 gallons on a 29 inch base at 45 pounds, and the honest difference between them is two inches of height and what the wall is made of. This one is listed at 49 inches where the three 1007300 parts are listed at 51; the sheets give both and we print what they say rather than explaining it. Buy this one when the cross-linked grade suits the chemistry, light needs keeping off the liquid, and the sheet's published 8 inch lid is worth having because the tank gets opened. The 1007300C26 and N42 are the natural walls for a duty where seeing the level through the shell wins, the C34 is the other black tank, and each is rated as its own sheet says. Below and above, the 1540200N51 lays 120 gallons down to 39 inches on a 32 inch base for the lowest possible profile, and the 1012800C26 steps up to 150 gallons at 59 inches.

Picked the 130 gallon tank? Add it to your cart above; freight is quoted to your ZIP before you pay anything.

A pump that stays flooded on 130 gallons

• Pump and suction: on a tank 49 inches tall the head above the base fitting is short, so pump placement is the whole game. Put the pump below the fitting, keep the suction leg short and level or falling toward the pump, and do not ask it to lift out of the top of the tank. A diaphragm or centrifugal pump on a shallow tank loses suction in the last inches, so a low level float or dry run cutout is the cheapest protection on the install, and on a crew tank that gets drawn down to nothing it is the part that saves the pump. Flood the suction before the first start rather than dry priming it.
• Outlet: the sheet lists the outlet as 1 Manway / Lid and names no bottom fitting diameter, material, thread or gasket. Tell us the liquid and the pipe at order and the draw-off is specified then; no size is printed here that the sheet does not carry.
• Access and venting: 8 inch lid on the top head at 49 inches, reachable standing. Fill through a dip tube rather than free-falling the liquid, seat the lid gasket clean every time, and run the vent outdoors on anything that fumes, sized to the filling pump.
• Structural: the sheet lists one flange line on the body.
• Service limit: 140 F / 60 C.

Short and worked is the profile of this tank, and both halves of that shape the plumbing. Because the head is short, the suction side gets the attention: short run, no high points, pump low, float fitted. Because it is worked, the fittings see hoses pulled across them, so the connector to hard pipe is flexible, the first valve sits on its own support rather than hanging off the wall, and one spare gasket for the specified fitting is on the shelf before it is needed. Keep the lid closed between refills. Name the liquid on the wall. Light the band of wall above the liquid line whenever the lid is off, because a tank that cycles wet and dry ages there first. Where the site freezes, trace or wrap the valve and the first pipe run; the body itself takes ice from the top down without harm.

Small duties, dark wall

Spray and vegetation crews mixing from a stand, wash racks and truck washes on soap or reclaim, small plants dosing polymer or hypochlorite, shops on rinse or coolant, greenhouses on nutrient stock, and barns on treated water or a blend that light would spoil. The black wall is there for the light-sensitive cases and the cost of it is a level you cannot see, so plan a sight tube or a float. The grade question is separate from the color question, and the cross-linked versus high density comparison is where to settle whether the cross-linked wall earns its price for your chemistry. Two things this tank is not: it is not a water reserve you should size by feel, and it is not a fire reserve, which is a system with its own sizing and freeze rules rather than a vessel you buy, as the fire-water reservoir design guide sets out. If containment is required, the Captor double wall freeboard guide shows what a second wall costs in usable gallons at this size.

Out of Lincoln at 45 pounds

The 1009500N48 is molded at Lincoln, Nebraska and moves as freight at class 300 as the sheet lists it, 29 inches by 29 inches by 49 inches on the pallet. The freight cost estimator prices the lane to your ZIP, and the listed price is before freight. At 45 pounds this is the lightest tank in the group and two people take it off a liftgate without ceremony, though a forklift and a pallet is still the way to do it if you have one. Water test before product even at this size: fill it, hold it a shift, read the base, the stand and the specified fitting, then drain and dry. Write the part number and the date on the stand or the log the day it lands, because a shop with three small black tanks on three stands cannot tell them apart a year later. Keep the delivery paperwork with the tank; the serial number on the shell is what a warranty claim starts from.
