Snyder Industries 250 Gallon ASTM HDPE Black Double Wall Tank

Daylight, a level slab and a tall narrow tank

Two things decide where this one goes, and the first is light. The shell is black, which keeps daylight out of the contents, and that is the reason a site picks this part number over the natural white listing standing next to it on the same 34 by 34 by 83 inch shell at the same 150 pounds. If the vessel is going under a skylight, beside a roller shutter that spends the day open, in a lit bay or anywhere outdoors under a canopy, the black wall is doing work that a white one is not. What it costs you is the level reading: on a white tank an operator sees the liquid through the shell from across the room, and on this one the only published opening is a lid at 83 inches, so plan how the level gets read before the tank is set rather than afterwards. The second is the slab. A base 34 inches square carrying a vessel nearly seven feet tall concentrates its load on very little ground: 2,085 pounds of water and 3,962 pounds at the published 1.9 rating, all of it on under eight square feet. The surface has to be flat, continuous and level under the entire footprint, with no rocking and nothing packed under one corner, and the tank wants securing against being knocked in a walkway, because a tall vessel on a small plan is the one a pallet truck catches. On a ground-bearing slab that is straightforward. On anything raised, suspended or previously patched, it is a question for whoever owns the structure. This sheet's own service limit is 120 F / 48 C, and it is worth saying plainly that the natural white listing in the identical shell carries a different figure. We print each sheet's own number on its own page and we do not borrow across the pair, because the figure that matters to you is the one against the part number you actually order. Two references belong before the order. The hardest service the wall sees is at the vapour line rather than under the liquid, which the wall thickness at the vapour saturated headspace guide works through, and it explains why an inspection from the liquid side misses it. The usable volume and the real headspace on a contained tank are not the nameplate figure either, which is the subject of the double wall freeboard sizing guide. Put your own turnover through the tank sizing calculator and take the freeboard discipline from the tank sizing guide. Where the duty in question is private fire water storage rather than chemical feed, that is a separate design problem and the fire water reservoir design guide for rural and remote sites is the place to take it; nothing here is a claim about that use.

The same 83 inch shell under four names

Four part numbers, one shell, four names. We print the name each sheet gives and interpret none of them; where a drawing, a spares list or an existing installation already names one of these part numbers, order that one and we will confirm the published figures against it before anything ships. What you can act on from this table is proportion and colour. Two of the four are black and two are not, and that is a decision about daylight rather than about chemistry. The 150 gallon row shares this exact 34 inch plan at 62 inches and 110 pounds, so stepping down costs you nothing on the floor and brings the lid twenty-one inches closer to a standing operator, which on a vessel filled by hand is a genuine daily difference. The 275 gallon row goes the other way entirely: more volume than this tank on a 47 inch plan at just 63 inches and 200 pounds, trading floor space for a top somebody can see into from one step. Three vessels, three shapes, and the room you are putting it in decides which. Measure the ceiling, measure the floor you can give up, and then work out which of the two is the constraint you cannot argue with. That answer is usually obvious once it is written down, and it is almost never the gallon figure that settles it.

Want us to check the fit? Send the site dimensions to 866-418-1777 or through a written quote request and we will confirm the tank, the pad and the freight.

What the 14 inch lid does and does not carry

• The outlet field: "1 Manway / Lid" and nothing else, with the inlet field blank. That names an opening, not a pipe size. No outlet dimension, thread, bulkhead, flange or valve is published on this sheet and none is claimed here. Give us the duty and the line size and we will confirm what this part number carries.
• The opening: a 14 inch threaded vented lid, the only one on the sheet, doing duty as the fill point, the inspection point and the cleaning access. Fourteen inches accepts a delivery coupling, a drop pipe and a lance; everything you want on top shares it.
• Reaching it: the lid is at 83 inches. On a black shell you cannot read the level from the floor either, so the access arrangement and the level indication should be designed together rather than separately.
• The vent: the lid is listed as vented. That path is the wall's protection on a fast fill and a hard pump-down, and on a tall, slim tank the level moves quickly for a given flow. Keep it clear and look at it every time the lid comes off.
• The space between the walls: no monitoring port, gauge or alarm is published, so that arrangement is specified separately. A scheduled look with the date written down is the minimum worth having.
• Structure: the sheet publishes no lifting lugs, no ladder lugs and no flange lines.
• Limits: 120 F / 48 C, a specific gravity rating of 1.9, and a 3 Year Warranty, as this sheet gives them.

Tell us the product at order time. The lid seal and any fitting we add are selected against the chemistry, and on a contained vessel those parts are the only route a release can take.

Outdoor dosing points and yards with no roof

A black contained tank in this shape goes where a white one would be working against the light: a dosing point under an open canopy, a wash bay or vehicle wash with the shutter up all day, an agricultural or horticultural chemical store, a plant room with a skylight over it, a quarry or wash plant reagent station, a metal finishing line beside a window, and any yard-side feed point where the vessel stands outdoors but a spill still has to be contained. Two hundred and fifty gallons on a three foot square is the practical part: it takes a hose delivery, it does not need a bund constructed round it, and it occupies a corner rather than a bay. Where it is outside, walk round it after weather and after any traffic near it, and keep the schedule for looking into the space between the walls the same in winter as in summer. The one thing to arrange deliberately is level indication, because a black wall gives you none.

Lincoln, Nebraska, one pallet, 150 pounds

Lincoln, Nebraska is the plant on this sheet and Nebraska the only ship-from state. Freight is LTL at class 250 with no NMFC number, and the shipping size is listed at 34 by 34 by 83 inches at 150 pounds. Price your own lane with the freight cost estimator; the listed price is before freight. One pallet position and 150 pounds puts this within a tail lift delivery and a pallet truck on most sites, so the height rather than the weight is what you plan around: measure the lintels, the roller shutter and any overhead pipework on the route, and remember that a tank standing nearly seven feet on the ground is taller again on a pallet. Take it under the base, never by the lid, and keep it upright through the building where the route allows. Set it on the finished, level surface in its final position, check it is plumb from two directions and secure it against being knocked before anything is connected. Fill it with clean water, hold the 2,085 pound load, and read the lid seal and the base all the way round. Drain it, let it dry, open the space between the walls and record the date on the shell. On a black tank, do one extra thing while the water is still in it: mark the outside of the shell at your working full level and at your stop level in paint, because from that day on nobody is going to see it through the wall. A photo of the tank on its pad, full, on day one is worth keeping; it is the baseline every later inspection is compared against.
