Snyder Industries 5600 Gallon ASTM Black Heavy Duty Vertical Storage Tank

When the roof is low and the liquid is heavy

This tank goes out rather than up: 142 inches across and 102 inches tall, so it fits under a pump house eave, a shed roof or an existing low bay where a tall column will not stand. The 1.9 rating is what makes it the right buy when the liquid is also dense. Outdoors, a low tank catches less wind and the manway is reached from a short platform. The cost of the shape is floor area. A rotationally moulded tank bears on its whole floor, so the pad under a 142 inch circle has to be level and in full contact everywhere; a low corner turns the load into a point load. Engineer it with our concrete pad sizing guide and put it inside a berm sized to the tank where the liquid is regulated. Check the volume against your use between fills in the tank sizing calculator and take the reserve and freeboard from the tank sizing guide.

What to check before you buy

1. The liquid. Check it against polyethylene in our chemical compatibility guide. If it is heavier than 1.9 times water or runs above 120 F in service, tell us; that is a different tank.
2. The outlet. This page lists the manway, not a bottom fitting. Tell us the liquid and the pipe you are tying into and we will confirm what this tank takes before anything is drilled. A wide, low tank has little head over a base fitting, so mount the transfer pump below the outlet and keep the suction run short.
3. The manway. 18 inch threaded and vented on the crown. The vent has to pass air as fast as the fill pump pushes liquid in, so keep it clear and run it outdoors if the liquid fumes.
4. The drawing. Snyder's drawing for 5250000N51 is linked under Technical Drawing on this page and shows the manway position and the base.

The same shell in other walls, and the tall alternatives

Snyder moulds this 142 inch shell in several walls. Where the liquid is harder on plastic than it is heavy, look at the 5600 gallon XLPE heavy duty tank 5250000N42, the 5600 gallon XLPE tank 5250000N40 and the 5600 gallon XLPE black tank 5250000N46. For water and lighter liquids, the 1.5 rated black version of this shell is also on our store. Near this volume in a different mould are the 5500 gallon XLPE tank 7000000N40 and the 6000 gallon black heavy duty tank 7000000C34; compare the diameter and height on each page. A fire reserve is designed as a system first; the fire water reservoir design guide lays it out.

Shipping and receiving

The tank ships LTL at freight class 300 from Snyder's plant at Philippi, West Virginia, 142 by 142 by 102 inches and 1,350 lb. At 142 inches across it is wider than a standard trailer, so it moves as an oversize load and the route to the pad matters: walk the gate, the doorway and any overhead lines before the truck is booked. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 5250000N51 on the bill of lading and walk round the base for transit damage. Fill it with water first, hold it a day, and look at the base and the pad edge before the working liquid goes in.

Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
