5,400 gallons at 1.9 specific gravity under eight feet, in white
The Snyder 7000400C26 is a natural white polyethylene vertical storage tank, 142 inches across and 91 inches tall, holding 5,400 gallons at 750 pounds. It is the low tank at this volume: a twelve foot base spreads a full tanker out under an eight foot roof, the 18 inch threaded, vented manway is reached from a step instead of a ladder, and the white wall shows the level in daylight. The sheet rates its wall for a specific gravity of 1.9, or 85,568 pounds of contents against 45,036 for water, the wall for concentrated acid, ferric and the heavy brines at strength. A 3 inch polypropylene female NPT bulkhead outlet, a 3 year warranty, and freight at class 400 from Chowchilla, California.
Want it on the pad this month? Check freight to your ZIP, add it to your cart above, and 866-418-1777 will confirm the ship date.
A full tanker of dense liquid, low
A 1.9 wall is sized for a liquid nearly twice as dense as water, and on a low wide shell the load goes into the floor rather than the wall: full at the rating it puts 85,568 pounds on a 142 inch circle, and a rotationally molded floor bears on all of it, so it stands on a slab engineered to the concrete pad sizing guide and in full contact with the floor, with a berm sized to the tank around it when the liquid is a regulated chemical. A low tank on a wide base has the lowest center of gravity in its class and needs the least strapping, and a manway at 91 inches is where a truck fills it without a ladder. The white wall shows the level through it, and shows a dense chemical's color, which matters when two tanks stand side by side.Feed rate times delivery interval is the volume, and the tank sizing calculator does that arithmetic; the reserve and the thermal freeboard on a dense liquid are in the tank sizing guide.
The 142 inch low tank in its grades, and the tall 5,300 and 5,500
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 7000400C26 (this tank, 1.9 SG) | 5,400 | 142 x 91 in | 750 lb |
| 7000400C34 | 5,400 | 142 x 91 in | 750 lb |
| 7000400C37 | 5,400 | 142 x 91 in | 750 lb |
| 7000400C37-BLACK (black) | 5,400 | 142 x 91 in | 750 lb |
| 1009200C37-BLACK (black, tall) | 5,300 | 164 in tall | see page |
| 7000000N40 (tall) | 5,500 | 120 x 132 in | 1,155 lb |
The C34 and C37 are the other general grades in this same low shell at this weight, and the C37-BLACK the black one for sun or a light-sensitive liquid; each is rated as its own sheet says. The 1009200C37-BLACK is the black 5,300 turned upright to 164 inches for a site with height and no floor, and the 7000000N40 stands 5,500 gallons on a 120 inch base at 132 inches in the heavier chemical wall.
Which wall for your chemical? Call 866-418-1777 with the name and the concentration, or send a quote request and we will pick the row.
The 3 inch outlet on a dense liquid
- Outlet: 3 inch polypropylene female NPT bulkhead fitting, at the base; tell us the liquid when ordering and the fitting is matched to it, with a flanged transition, a flexible connector to hard pipe, and the valve supported off the pad in the material the chemical calls for.
- Access: 18 inch threaded, vented manway, 91 inches up, reached from a step; fill by tote pump or truck through a dip tube, vent outside on acid and caustic service, and size the vent for the delivery pump.
- Service limit: 120 F / 48 C.
A 3 inch outlet drains a full tank in a working shift and never starves a transfer pump; put the pump below the outlet, where gravity keeps it primed, and let a low-level float shut it down before it runs dry. Keep the manway closed against vapor loss, label the tank so the fire inspector and the workplace inspector read the same thing, and inspect the headspace wall from the manway with a light; that is where a chemical tank ages first. In a freezing climate the outlet valve and the first run of pipe get heat trace or insulation; the tank body itself can ice from the top down and come to no harm.
Where a low 5,400 in the heavy wall goes
Ferric and other dense coagulants at a water plant with a low chemical building, caustic or acid at a small industrial plant, brine at a food plant, and liquid fertilizer at a co-op with a low shed. It is not the wall a fire reserve needs, as the fire-water reservoir design guide makes plain, though it will hold water. Reuse systems dose chemical between storage stages; the industrial water reuse tank topology article maps where this size sits.
From Chowchilla to the pad
The 7000400C26 ships from Chowchilla, California as freight at class 400 as the sheet lists it; at 142 inches across it is a load the carrier handles outside the trailer, and the freight cost estimator prices the lane to your ZIP, with the listed price before freight. A forklift with long forks sets 750 pounds on the pad; a crane strap goes under the tank, never through the manway. Fill it with water to the manway once, hold it, and check the outlet fitting and the pad edge, then drain and dry before the chemical goes in. Save the pallet; a tank this wide that ever has to move again is easier to move on it. Walk the base after the first hard rain; a pad that shifts shows it at the edge first.
Freight and documents
Ships from: Chowchilla, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 7000400C26.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
