A 2500 gallon 30 degree cone bottom tank that arrives on its own poly stand
The Norwesco 2500 gallon 30 degree cone bottom tank with poly stand, part number 40672, is the tank and a polyethylene stand bought as one item. Assembled, it is 99 inches across and 116 inches tall and weighs 889 lb. The tank is white polyethylene with a 2 inch polypropylene female NPT bulkhead fitting at the point of the cone and a 16 inch threaded vented manway on top. It is rated for liquids up to 1.5 specific gravity, 12.52 lb per gallon. Norwesco states the resin is FDA compliant, the service limit is 120 F, and the warranty is 3 years. The same assembly comes in black as the 2500 gallon 30 degree cone bottom tank with poly stand in black, for liquids that should not see light, and at a 1.9 rating as the 2500 gallon 30 degree heavy duty cone bottom tank with poly stand in blue for liquids heavier than 1.5 times water.
White, black or heavy duty? Call 866-418-1777 with the liquid, or get freight to your ZIP and add it to your cart above.
Buying the assembly instead of designing a structure
The decision on this page is not the capacity or the angle; it is whether the support comes with the tank. A cone bottom tank has no flat floor and cannot stand on its own point, so on the tank-only route somebody has to design, build and inspect a frame that holds a full tank at the feet, and that frame has its own lead time. This part number is the route that arrives complete: Norwesco's stand, made for this cone and this diameter, on the same pallet as the tank. The jobs are fertilizer blending, brine and water treatment chemical batching, and bulk storage where the tank is emptied between fills. The 2500 gallon 30 degree cone bottom tank with poly stand buyer's guide covers siting and setup in detail.
What goes in it
Water, liquid fertilizer, brine and the common chemicals polyethylene handles, up to 1.5 times the weight of water and under 120 F. Check the liquid in the chemical compatibility guide before the first fill; urea solution, calcium chloride, sodium hypochlorite, ferric chloride and phosphoric acid are the entries buyers of this size ask about. Use the tank sizing calculator and the tank sizing guide for the volume.
What to check before you buy
- The height and the route in. 116 inches assembled and 99 inches across. This is an outdoor pad or high bay assembly; it does not tip to clear a door frame. Measure the opening, the ceiling and the path from the truck before you order.
- The floor. A flat, level, continuous 99 inch circle with no drain, joint or slope under the stand, designed by your installer for the full weight of tank and contents at the feet. Level the stand across both diagonals before the tank goes in.
- Clearance under the outlet. The 2 inch bulkhead fitting sits at the point of the cone inside the stand; Norwesco's drawing, linked under Technical Drawing on this page, gives the outlet height. Measure the valve or pump inlet before the order.
- The valve. Fit it before the tank is seated and support the first length of pipe on its own so the fitting carries liquid, not hardware.
- The manway. 16 inches, threaded and vented, reached from a platform at this height; plan the fill and the level sender so routine work does not need a climb.
- Anchoring. No anchor hardware comes with the stand; if your site needs it bolted down, that is yours to supply.
Sizes nearby
One step down, tank only on a shallow cone: the 1720 gallon 15 degree cone bottom tank. One step up in the same style: the 3000 gallon 30 degree cone bottom tank with poly stand. The swatches above the price switch between the white, black and heavy duty versions of this assembly.
Shipping and receiving
The assembly ships as an oversize LTL load from the nearest of Norwesco's Griffin, Georgia, Hanford, California and Lancaster, Ohio plants, 116 by 99 by 99 inches and 889 lb. Oversize freight is priced on the space it takes rather than the weight, so the lane matters: the listed price is before freight, and the freight cost estimator gives the cost to your ZIP. Plan a forklift at the receiving end. When it arrives, check the part number 40672 on the bill of lading, look at the stand legs and the cone for transit damage before the driver leaves, and fill with water the first time so any problem shows up with something harmless in the tank.
Questions before you order? Call 866-418-1777 or request a written quote.
Freight and documents
Ships from: Hanford, CA; Griffin, GA; Lancaster, OH. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 40672.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 2500 Gallon 30 Degree Cone Bottom Tank with Poly Stand video (65 seconds) with dimensions, fittings and shipping notes.
Ready to order?
Add it to your cart at the top of this page, get LTL freight to your ZIP, request a written quote, or call 866-418-1777. The listed price is before freight.
3 Year Warranty
