A 3000 gallon 15 degree cone bottom tank with a 3 inch outlet
The Norwesco 3000 gallon 15 degree cone bottom tank, part number 45141, is a white polyethylene tank 91 inches in diameter and 120 inches tall, weighing 461 lb empty. It is the tallest tank on Norwesco's 91 inch, 15 degree cone: the same footprint as the smaller 15 degree tanks, with ten feet of height carrying the volume. The outlet is a 3 inch polypropylene female NPT bulkhead fitting at the point of the cone, sized so that 3000 gallons leaves the tank at a useful rate; on top is a 16 inch threaded vented manway. The rating is 1.5 specific gravity, 12.52 lb per gallon. Norwesco states the resin is FDA compliant, the service limit is 120 F, and the warranty is 3 years. It needs Norwesco's stand, part number 64090, sold separately. For liquids heavier than 1.5 times water, the same tank is made at a 1.9 rating as the 3000 gallon 15 degree heavy duty cone bottom tank in blue.
Standard or heavy duty, 15 or 30 degrees? Call 866-418-1777 with the liquid and the site, or get freight to your ZIP and add it to your cart above.
Where it goes
Bulk fertilizer and brine storage, water treatment chemical make-up at plant scale, and any job where a free flowing liquid is drawn off by gravity or a pump and the tank should empty between fills. A 15 degree cone is slow on thick liquids and does not clear settled solids the way a steeper cone does; if your batches drop solids, the 3000 gallon 30 degree cone bottom tank and the 3000 gallon 30 degree cone bottom tank, second version are the same volume on a steeper cone, and the 3000 gallon 30 degree heavy duty cone bottom tank is the 1.9 rated version. Our buyer's guide to 15, 30 and 45 degree cones sets the angles side by side, and the 3000 gallon 15 degree cone bottom tank buyer's guide covers this tank in detail.
What goes in it
Water, liquid fertilizer, brine and the common chemicals polyethylene handles, up to 1.5 times the weight of water and under 120 F. Check the liquid in the chemical compatibility guide first; urea solution, calcium chloride, sodium hypochlorite, aluminum sulfate and sulfuric acid are the entries buyers of this size ask about. Use the tank sizing calculator and the tank sizing guide for the volume.
Openings, fittings and the stand
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting at the point of the cone. Keep the valve and the first run of pipe at 3 inches so the drain speed is not throttled at the first elbow. With a full tank above it, fit the valve before the tank is seated and support the pipe on its own.
- Manway. A 16 inch threaded vented manway, reached from a platform at 120 inches; plan the fill and the level sender so routine work never needs a climb.
- Stand. Norwesco's stand 64090 serves the 91 inch, 15 degree family. Its height sets what fits under the outlet; measure the valve or pump before you order.
- Floor. A 91 inch circle, flat, level and continuous, designed by your installer for the full weight of tank and contents at the stand feet.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet and manway positions.
Sizes nearby
One step down on a 30 degree cone: the 2500 gallon 30 degree cone bottom tank. One step up on the same shallow cone: the 4950 gallon 15 degree cone bottom tank. The swatches above the price switch between the standard and heavy duty versions of this tank.
Shipping and receiving
The tank ships as an oversize LTL load from the nearest of Norwesco's Shawnee, Oklahoma, Sheldon, Iowa and Tooele, Utah plants, 91 by 91 by 120 inches and 461 lb. Oversize freight is priced on the space it takes rather than the weight, so the lane matters: the listed price is before freight, and the freight cost estimator gives the cost to your ZIP. A stand ordered with the tank travels with it, and plan a forklift or a crew at the receiving end. At the tailgate, check the part number 45141 against the bill of lading, look over the cone and the 3 inch fitting before signing, and fill with water the first time so any problem shows up with something harmless in the tank.
Questions before you order? Call 866-418-1777 or request a written quote.
Freight and documents
Ships from: Sheldon, IA; Shawnee, OK; Tooele, UT. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 45141.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 3000 Gallon 15 Degree Cone Bottom Tank video (66 seconds) with dimensions, fittings and shipping notes.
