A 3000 gallon 15 degree cone bottom tank rated for heavy liquids, in light blue
The Norwesco 3000 gallon 15 degree cone bottom tank in blue, part number 45242, is a high density linear polyethylene process tank that drains completely: the floor slopes at 15 degrees to a centre outlet, so nothing is left behind between batches. The tank is 91 inches in diameter and 120 inches tall, weighs 531 lb empty, and is rated for liquids up to 1.9 specific gravity, a maximum of 15.87 lb per gallon. 3000 gallons of water weighs 25020 lb; a full load at the rating limit is 47538 lb. It comes with a 3 inch polypropylene female NPT bulkhead fitting at the bottom outlet and a 16 inch threaded vented manway on top; no inlet fitting is installed, so the top is yours to drill for fill, vent and level where your process wants them. The resin is FDA compliant per Norwesco, the service limit is 120 F (48 C), and Norwesco backs it with a 3 year warranty. A cone bottom tank has no flat base and needs its stand: Norwesco's stand N-64090 is required and sold separately.
Ordering the tank and the stand together? Call 866-418-1777 and we put both on one order, or get freight to your ZIP and add it to your cart above.
Why a 15 degree cone at 1.9
Buy a cone bottom when the liquid must leave the tank completely and repeatedly: a batch made up, drawn down and made up again; a solution carrying something in suspension that must not settle and stay; a bulk supply where the last of the tank is worth as much as the first. Fifteen degrees is the shallow end of Norwesco's cone range, which keeps the overall height down and the stand short; steeper cones move solids faster but stand taller. Our cone bottom buyers guide to 15, 30 and 45 degree cones walks through the choice, and the 3000 gallon 15 degree cone bottom buyers guide covers this size in particular. The 1.9 rating is for heavy liquids: concentrated fertilizers, brines, many acids and caustics run well above 1.5. For water and thin liquids the same tank in white at the standard 1.5 rating is the lighter choice.
What goes in it
Polyethylene handles water, most fertilizers and many common chemicals; the 1.9 rating widens that to the heavy ones. Check the liquid in our chemical compatibility guide before the first fill; the entries for sulfuric acid, sodium hypochlorite, ferric chloride, potassium hydroxide and calcium chloride are the ones cone bottom buyers ask about most. Keep the contents under 120 F. Our guide to top fitting placement for fill, vent, level and vapor recovery is the one to read before anyone drills the top. For the volume, use the tank sizing calculator and tank sizing guide.
Openings, fittings and the stand
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting at the point of the cone, factory installed. Your valve threads straight in.
- Top. A 16 inch threaded vented manway, and no inlet fitting. Decide the fill, vent and level positions before the tank arrives and have the bulkhead fittings on the same order.
- Stand. Required, Norwesco part N-64090, sold separately. The stand sets the outlet height, which decides what fits under the cone: a valve and a hose, a pump inlet or a drum. Measure that equipment first.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the cone geometry, the outlet and the manway.
Sizes nearby
Same volume with a steeper cone: the 3000 gallon 30 degree cone bottom tank rated 1.9, the 3000 gallon 30 degree cone bottom tank and the 3000 gallon 30 degree cone bottom tank in its second version. One size down: the 2500 gallon 30 degree cone bottom tank. One size up at the same angle: the 4950 gallon 15 degree cone bottom tank.
Shipping and receiving
At 91 inches across and 120 inches tall this tank ships as oversize freight from the nearest of Norwesco's Shawnee, Sheldon or Tooele plants, 531 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, and a stand on the same order rides with the tank. You need a forklift or a loader with straps to unload it; a liftgate will not take it. Set the stand in its final position first, level it across both diagonals, then lower the tank in and turn it so the outlet points where the pipe runs. Check the part number against 45242 on the bill of lading, and fill with water the first time so any problem shows up with something harmless in the tank.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Sheldon, IA; Shawnee, OK; Tooele, UT. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 45242.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Norwesco 3000 Gallon 15 Degree HDPE Cone Bottom Tank in Blue video (64 seconds) with dimensions, fittings and shipping notes.
