A 2500 gallon 30 degree cone bottom tank in black, with its poly stand
The Norwesco 2500 gallon 30 degree cone bottom tank with poly stand in black, part number 42025, is a polyethylene tank 99 inches in diameter and 116 inches tall on its stand, weighing 889 lb for the tank and stand together. A cone bottom tank drains itself completely: the floor slopes to a single low point, so settled solids and the last few gallons leave through the outlet instead of sitting in a flat bottom. The 30 degree cone is the middle of Norwesco's range, steep enough to move most fertilizers and chemicals, short enough to keep the tank under ten feet. The stand comes with it, which is the part buyers of other cone tanks forget to order. It comes with a 2 inch outlet at the cone and a 16 inch lid on top. The tank is rated for liquids up to 1.5 specific gravity with a service limit of 120 F, and the resin is FDA compliant per Norwesco. Full of water it holds 20850 lb. Black keeps light out, which slows algae in water and protects light sensitive liquids.
Is this the right cone? Call 866-418-1777 with what you are mixing or storing, or get freight to your ZIP and add it to your cart above.
What a cone bottom tank is for
Mixing and batching liquid fertilizer, holding chemicals that settle or crystallize, process tanks that must empty fully between batches, and any job where leaving product in the bottom costs money or contaminates the next load. The included poly stand lifts the cone high enough to get a valve and a hose, or a drum, underneath. Our 2500 gallon 30 degree cone bottom buyer's guide covers this size in detail. Check anything other than water in our chemical compatibility guide first; the entries for urea solution, calcium chloride, sodium hypochlorite, phosphoric acid and sulfuric acid are the ones cone tank buyers ask about most. For the volume, use the tank sizing calculator and tank sizing guide.
Openings, the stand and what to check before you buy
- Outlet. A 2 inch outlet at the point of the cone. Your valve goes on before the first fill. Support the valve and the first length of pipe so the fitting carries liquid, not hardware, and leave room under the stand for both.
- Lid. A 16 inch lid on top for filling, a mixer or a level sensor, and access for cleaning. At 116 inches up, plan a step or a platform for whoever opens it.
- The stand. Included, moulded in polyethylene to the 30 degree cone. It needs a flat, level, continuous floor under its whole base; a full tank on a stand is a concentrated load, and the floor rating belongs to your engineer.
- The liquid. The 1.5 rating covers liquids up to 1.5 times the weight of water at up to 120 F. For denser fertilizers and chemicals, see the heavy duty version below.
- Height. 116 inches overall. Measure the door and the ceiling of any building it is going into before you order.
Norwesco's drawing for this tank is linked on this page under Technical Drawing. It shows the cone, the outlet position and the overall height on the stand.
Versions and sizes nearby
The same tank and stand in white, for liquids where you want to see the level through the wall: the 2500 gallon 30 degree cone bottom tank with poly stand in white. The heavy duty version, rated 1.9, in light blue: the 2500 gallon 30 degree heavy duty cone bottom tank with poly stand in blue. One size up: the 3000 gallon 30 degree cone bottom tank with poly stand. For a shallower cone and a shorter tank: the 1720 gallon 15 degree cone bottom tank, stand sold separately.
Shipping and receiving
The tank and stand are oversize freight, 116 by 99 by 99 inches and 889 lb together, on a flatbed from the nearest of Norwesco's plants in Griffin, Georgia, Hanford, California, St. Bonifacius, Minnesota and Washington Court House, Ohio. You need a forklift or several hands and a clear bay to take them off the truck. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 42025 on the bill of lading, look over the cone, the outlet and the stand for transit damage, level the stand across both diagonals, set the tank in it, and fill with water the first time before anything else goes in.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Hanford, CA; Griffin, GA; St. Bonifacius, MN; Washington Court House, OH. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 42025.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Norwesco 2500 Gallon 30 Degree Cone Bottom Tank with Poly Stand in Black video (69 seconds) with dimensions, fittings and shipping notes.
