A 5500 gallon 30 degree cone bottom tank for blending and full drain-down
The Norwesco 5500 gallon 30 degree cone bottom tank, part number 40549, is a white polyethylene tank 119 inches in diameter and 148 inches tall, weighing 1185 lb empty. The 30 degree cone bottom sends the whole load to the outlet at the point of the cone, so settled material slides out with the liquid and nothing is left to pump or scrape. It comes with a 3 inch polypropylene female NPT bulkhead fitting at the cone outlet and a 16 inch threaded vented manway on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 5500 gallons of water weighs 45870 lb. The resin is FDA compliant per Norwesco, the service limit is 120 F, and Norwesco backs it with a 3 year warranty. A cone bottom tank needs a stand: Norwesco pairs this one with stand N-60358, sold separately.
Planning a blend plant or a bulk chemical tank? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 and we will confirm the tank and its stand on one order.
Where this tank goes
Fertilizer blending and storage at a dealer or a large farm, water and wastewater chemical make-up, brine, and any batch process that needs the tank empty between runs are the usual jobs. The 30 degree cone is steep enough that settled solids slide to the outlet rather than ledging on the slope, and short enough to keep the tank at 148 inches overall. A 119 inch diameter needs a wide door or an outdoor pad, so measure the route in before you commit. Our cone bottom buyers guide comparing 15, 30 and 45 degree cones explains the angle choice, and the 5500 gallon 30 degree cone bottom buyers guide covers this tank in detail. For the volume itself, use the tank sizing calculator and tank sizing guide.
What goes in it
Water, liquid fertilizer and the industrial and treatment chemicals that polyethylene handles. Check the liquid in our chemical compatibility guide before the first fill; the entries for urea solution, sulfuric acid, sodium hypochlorite, ferric chloride and phosphoric acid are the ones cone bottom buyers ask about most. The 1.5 rating means a liquid up to 1.5 times the weight of water, 12.52 lb per gallon. Heavier liquids belong in the heavy duty version, the 5500 gallon 30 degree cone bottom tank in light blue, rated to 1.9. Keep the contents under 120 F. White lets you read the level through the wall and lets light reach the contents; if that matters for your liquid, ask us about a darker tank.
Openings, fittings and the stand
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting at the point of the cone. Thread the valve in before the tank is set, and support the first length of pipe on its own so the fitting carries liquid and not hardware.
- Manway. A 16 inch threaded vented manway on top: fill from a hose or a pump, mount a small mixer, drop a float in, or get a hand and a brush inside.
- Stand. Stand N-60358 is required and sold separately. With tank, stand and 45870 lb of water the floor carries a concentrated load; your installer and Norwesco's documentation, not this page, set the slab.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the cone geometry, the outlet position and the overall height with the manway.
Sizes nearby
One size down, with a shallower cone: the 4950 gallon 15 degree cone bottom tank. One size up, also with a 15 degree cone: the 6000 gallon 15 degree cone bottom tank. The swatches above the price switch between the standard and heavy duty versions of this tank.
Shipping and receiving
This is an oversize load. It ships by flatbed or dedicated truck from the nearest of Norwesco's plants in Shawnee, Oklahoma, St. Bonifacius, Minnesota, and Washington Court House, Ohio, 148 by 119 by 119 inches and 1185 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, and a written quote is available for a job that needs paperwork. Have a forklift with long forks or a loader with wide straps ready; never lift by a chain around the cone or a strap through the manway. At the tailgate, check the part number against 40549 on the bill of lading, look over the cone, the outlet fitting and the manway for transit damage, set the tank in its stand on a level floor, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: St. Bonifacius, MN; Washington Court House, OH; Shawnee, OK. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 40549.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 5500 Gallon 30 Degree Cone Bottom Tank video (70 seconds) with dimensions, fittings and shipping notes.
