Norwesco 110 Gallon Portable Flat Bottom Utility Tank in White

In a pickup, on a UTV or on the ground

At 48 by 35 inches the tank sits across a full size pickup bed between the wheel wells with room to spare, and at 18 inches tall it stays below the bed rail, so the tonneau or the tailgate closes over it. That low profile is the reason to buy a flat bottom utility tank instead of a leg tank of the same volume: the weight rides low, nothing sticks up to catch a branch, and one person can lift it in empty at 56 lb. Full of water it is close to 917 lb, which a half ton truck carries but a UTV may not, so check the vehicle's payload rating against the full weight, not the empty one. Strap it down in every direction the vehicle can move; a full tank that shifts under braking carries a lot of momentum. On the ground it needs a flat, continuous surface under the whole base. Our guide to Norwesco portable utility tanks and the agricultural exemption for farm fleet use covers how these tanks are classified on the road.

What goes in it

Water for livestock, a garden or a remote site, spray mix for a small sprayer, and the common farm chemicals that polyethylene handles are the normal loads. Check anything other than water in our chemical compatibility guide before the first fill, and ask us if the liquid is not on the list. Liquids heavier than 1.5 times water are outside this tank's rating. For a tank that stays put as a reservoir rather than riding in a truck, the tank sizing calculator and the tank sizing guide will tell you whether 110 gallons covers the draw between refills.

Openings and fittings

1. Outlet. A 1 inch polypropylene female NPT bulkhead fitting, factory installed. A 1 inch valve, hose barb or garden hose adapter threads straight into it. Support the valve and the first length of hose so the fitting carries liquid, not hardware.
2. Lid. A 5 inch hinged lid on top. It is a fill and inspection opening, wide enough for a hose or a small pump pickup; it is not a manway you can reach into.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet and lid positions for planning the plumbing and the tie-downs.

Sizes nearby

One size down: the 100 gallon utility tank. One size up in the same flat bottom shape: the 150 gallon portable flat bottom utility tank. Measure the bed or the rack before choosing between them; the extra gallons are only useful if the tank still fits with the tailgate closed.

Shipping and receiving

The tank ships LTL, NMFC 156600-03, from the nearest of Norwesco's plants that make it: Fairfield, Texas; Griffin, Georgia; Hanford, California; Lancaster, Ohio; Shawnee, Oklahoma; Sheldon, Iowa; or St. Bonifacius, Minnesota. On the pallet it is 48 by 35 by 18 inches and 56 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, and a written quote is available for a job that needs paperwork. At the tailgate, check the part number 42349 against the bill of lading, look over the base and the corners for transit damage, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
