A 200 gallon horizontal cradle tank for a truck bed or a saddle
The Norwesco 200 gallon horizontal cradle tank, part number 41305, is a white polyethylene tank 31 inches in diameter and 61 inches long, weighing 82 lb empty. A cradle tank is a plain round horizontal tank with no moulded legs; it sits in a cradle, a saddle or a pair of blocks that you supply or build, which is what lets it go where a leg tank cannot: across a pickup bed between the wheel wells, on a sprayer frame, on a skid or in a rack. It comes with an 8 inch lid on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals, with a service limit of 120 F. The resin is FDA compliant per Norwesco. Full of water it holds 1668 lb, which is within the payload of most full size pickups. The white wall lets you read the level from outside.
Is this the right size? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with the truck, sprayer or rack it is going on.
Where it goes
Water or spray mix in a pickup bed, a nurse tank on a small sprayer, a supply tank in a rack on a utility vehicle, and a fixed tank in a shop or a barn where a round tank on blocks is simpler than a tank with legs. At 31 inches across and 61 inches long it fits across most full size pickup beds and along most compact ones; measure between the wheel wells before you order. Because it is round, it has to be cradled: the cradle takes the weight along the length of the tank, not at two points, and the straps go over the tank and down to the cradle or the bed. Our note on concrete pad sizing for polyethylene tanks is more than this tank needs, but the same rule applies on a smaller scale: continuous support under the tank, never a point load. For the volume itself, use the tank sizing calculator and tank sizing guide.
What to check before you buy
- The cradle. Not included. A cradle or saddle shaped to a 31 inch diameter, supporting the tank along most of its 61 inch length, with no sharp edges against the wall. Timber saddles cut to the radius work; two loose blocks under a full tank do not.
- The lid. One 8 inch lid on top for filling and venting. It is not a manway; clean the tank through the lid with a wand.
- The outlet. No outlet fitting is listed on this tank. Tell us where you want the drain and what size, and we confirm what ships on the tank and what to add before it leaves the plant.
- The liquid. Polyethylene handles water, most fertilizers and many common chemicals. Heavier than 1.5 times water, or hotter than 120 F, needs a different tank.
- Tie-down. Two straps over the body, pulling down into the cradle, with the lid clear. A round tank with a loose strap rolls; check the straps after the first mile with a load.
Norwesco's drawing for this tank is linked on this page under Technical Drawing. It shows the lid position and the outside dimensions for cutting the cradle.
Sizes nearby
If the tank has to sit lower in the bed, the elliptical shape is the answer: the 200 gallon horizontal elliptical cradle tank holds the same volume with less height. One size up in the elliptical shape: the 300 gallon horizontal elliptical cradle tank.
Shipping and receiving
The tank ships LTL freight, NMFC 156600-03, from Norwesco's Sheldon, Iowa plant, 61 by 24 by 48 inches and 82 lb on a pallet. Two people can lift it off the truck. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote for a job that needs paperwork. At the tailgate, check the part number against 41305 on the bill of lading, roll the tank over and look at the whole wall for transit damage, and fill it with water the first time in its cradle before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Sheldon, IA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 41305.
See this tank
Product video. Watch the Norwesco 200 Gallon Plastic Horizontal Cradle Tank video (65 seconds) with dimensions, fittings and shipping notes.
