A 2000 gallon black heavy duty vertical tank that opens from a step
The Norwesco 2000 gallon black heavy duty vertical storage tank, part number 44127B, is a rotomolded polyethylene tank 90 inches in diameter and 84 inches tall, weighing 340 lb empty. It is a low, wide tank in Norwesco's heavy duty wall, rated for liquids up to 1.9 specific gravity, which takes in water, every common liquid fertilizer and most of the chemical solutions polyethylene handles; 2000 gallons of water weighs 16680 lb, and at the full 1.9 rating the contents can reach 31692 lb. It comes with a 2 inch polypropylene female NPT bulkhead fitting as the outlet and a 16 inch threaded vented manway on top. The resin is FDA compliant per Norwesco, Norwesco lists its water tanks under NSF/ANSI 61 (the listing names no models), the service limit is 120 F, and Norwesco backs the heavy duty tank with a 5 year warranty. Black keeps light out of the contents, which slows algae in water and protects light sensitive liquids.
Storing something heavier than water? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with the liquid and its specific gravity.
Where it goes and what it holds
This is the heavy duty tank for a site with a low roof: a fertilizer day tank in a sprayer shed, a chemical feed tank in a treatment building, a brine or wash water tank under a canopy. At 84 inches, seven feet even, the manway opens from a step and the whole tank clears most shed headers. The heavy duty wall is what you pay for: liquids denser than water put more stress on the wall near the base, and the 1.9 rating is built for it, with a warranty two years longer than the standard tank. For plain water the standard wall tank in the same mould is the cheaper choice. Check the liquid in our chemical compatibility guide before the first fill and keep it under 120 F. A full tank puts more than eight tons on a circle 90 inches across, so it needs a flat, continuous, level pad under the entire base; our guide to concrete pad sizing for above ground polyethylene tanks sets out the slab. If you are weighing this tank against the other makers' 2000 gallon verticals we stock, our 2000 gallon vertical storage tank comparison puts them side by side, and the industrial water reuse storage guide covers how a tank this size fits a reuse train. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. Your valve, camlock or pump suction threads straight in. Support the valve and the first length of pipe within a foot of the wall so the fitting carries liquid, not hardware.
- Manway. A 16 inch threaded vented manway on top: fill from a hose, drop a float or a level sensor in, and get a hand and a brush inside to clean. Leave the vent clear so air can move as the level changes.
- Extra ports. Only the one outlet comes installed. A recirculation return, a second draw or an overflow means extra bulkhead fittings; tell us when you order and we quote them with the tank.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height, the manway position and the base profile.
Sizes nearby
The same heavy duty wall in light blue is the 2000 gallon light blue heavy duty vertical tank. The standard 1.5 wall in this mould comes as the 2000 gallon black vertical tank or in white as the 2000 gallon white vertical tank. Norwesco also makes a second 2000 gallon heavy duty mould, the 2000 gallon black heavy duty vertical tank 47849; compare its diameter and height on its page. Nearby sizes: the 1700 gallon black vertical tank below it and the 2100 gallon black vertical tank above it. The colour and wall swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL at freight class 400 from Norwesco's Washougal, Washington plant as a 90 by 90 by 84 inch load weighing 340 lb. Two people can walk it off a liftgate; it is bulky rather than heavy. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 44127B on the bill of lading, look over the base and the outlet fitting for transit damage, and fill with water the first time before the tank carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Washougal, WA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44127B.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
