Norwesco 2000 Gallon Black Heavy Duty Vertical Storage Tank

Where a tall, narrow tank wins

Pick 47849 when floor is the thing you are short of: a chemical feed room at a water plant, the corner of a mix shed, a line of tanks against a wall, or a fenced pad between two buildings. It takes less than a third of the floor of a wide 2000 gallon tank and gives the height back in exchange, so it needs a ceiling or sky well above thirteen feet and a ladder or a platform to reach the manway. A tall narrow tank is also more sensitive to a pad that is not level and to wind if it sits outdoors empty, so set it on a flat, continuous slab and consider tie-downs on an exposed site. Full of water it puts about 8 tons on a small circle, more with a dense liquid. Our guide to sizing a concrete pad under an above-ground polyethylene tank covers the slab. If you are weighing this against other makers' tanks of the same size, our 2000 gallon vertical tank comparison lays the options side by side.

What goes in it

Liquid fertilizers, brines, many acids and bases, and water. The 1.9 rating is about weight, not chemistry, so check the liquid in our chemical compatibility guide before it goes in, and keep the contents under 120 F; polyethylene softens as it warms and the rating assumes that ceiling. If the liquid is plain water, the standard duty 2000 gallon tanks do the same job with a 3 year warranty. For the volume, the tank sizing calculator and tank sizing guide turn a delivery size and a draw rate into gallons.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. Your valve, camlock or hose adapter threads straight into it. Support the valve and the first length of pipe on their own and use a flexible connector before any rigid run.
2. Manway. A 16 inch threaded vented manway on top, reached from a ladder or a platform. The vent lets air move as the level changes; never plug it.
3. Inlet. No separate inlet fitting is installed. Tell us before the order ships if you want a fill fitting at a set height.
4. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet position relative to the manway.

Sizes and grades nearby

The same slim heavy duty tank in blue, Norwesco's usual colour for chemical service, and the white standard duty version are reachable from the colour swatches above the price. On a wider, shorter shell Norwesco makes the 2000 gallon black heavy duty vertical tank, its light blue twin, and the standard duty 2000 gallon black vertical tank. One size down is the 1700 gallon black vertical tank; one size up is the 2100 gallon black vertical tank.

Shipping and receiving

The tank ships LTL at freight class 300 from the nearest of Norwesco's Griffin, Georgia, Hanford, California and St. Bonifacius, Minnesota plants, 64 by 64 by 152 inches and 509 lb, on its side on a flatbed. Have a forklift with straps or three people and a soft landing ready, and room to stand it up. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 47849 on the bill of lading, look over the whole shell for transit damage before signing, and fill it with water the first time.

Questions before you order? Call 866-418-1777.
