A 2000 gallon light blue heavy duty vertical tank, low and wide
The Norwesco 2000 gallon light blue heavy duty vertical storage tank, part number 44127, is a rotomolded polyethylene tank 90 inches in diameter and 84 inches tall, weighing 340 lb empty. It is a squat tank, wider than it is tall, in Norwesco's heavy duty wall rated for liquids up to 1.9 specific gravity. That takes in water, most liquid fertilizers and many of the chemical solutions polyethylene handles; 2000 gallons of water weighs 16,680 lb, and at the full 1.9 rating the contents can reach 31,692 lb. It comes with a 2 inch polypropylene female NPT bulkhead fitting with a siphon tube as the outlet and a 16 inch threaded vented manway on top. The resin is FDA compliant per Norwesco, the service limit is 120 F, and Norwesco backs the tank with a 5 year warranty. Light blue absorbs less of the sun's heat than black, which keeps the contents cooler on an exposed pad.
Will it fit under your roof? Call 866-418-1777 with the clear height and the liquid, or get freight to your ZIP and add it to your cart above.
Where it goes and what it holds
Buy this shape when height is the constraint: under a lean-to, inside a shed with a low header, beneath a mezzanine, or anywhere a taller 2000 gallon tank would put the manway out of reach. At 84 inches, seven feet even, most people can open the manway from a step. The heavy duty wall is for liquid fertilizer, chemical feed and other loads heavier than water, and for a tank that stays full year round; for plain water, the 1.1 rated water version below does the job. Check anything other than water in our chemical compatibility guide and keep it under 120 F. A full tank puts more than eight tons on a circle 90 inches across, so it needs a flat, continuous, level pad under the entire base; our guide to concrete pad sizing for above ground polyethylene tanks sets out the slab. Our 2000 gallon vertical storage tank comparison puts the makers side by side. If the tank is a fire reserve, our guide to fire water reservoir design for rural and remote sites covers sizing and freeze protection. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 2 inch polypropylene female NPT bulkhead fitting with a siphon tube, factory installed. Your valve, camlock or pump suction threads straight in. Support the valve and the first length of pipe within a foot of the wall so the fitting carries liquid, not hardware.
- Manway. A 16 inch threaded vented manway on top: fill from a hose, drop a float or a level sensor in, and get a hand and a brush inside to clean.
- Extra ports. Only the one outlet comes installed. A recirculation return, a second draw or an overflow means extra bulkhead fittings; tell us when you order and we add them to the same order.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height, the manway position and the base profile.
Sizes nearby
The same heavy duty tank in black, which keeps light out of the contents and slows algae, is the 2000 gallon black heavy duty vertical tank 44127B. The standard 1.5 rated version is the 2000 gallon white vertical tank 44125, with a black standard tank in part 44125B. For water only, the 1.1 rated version is the 2000 gallon black water tank 44129. Norwesco also makes a second 2000 gallon heavy duty mould, the 2000 gallon black heavy duty vertical tank 47849; compare its diameter and height on its page. Nearby sizes: the 1700 gallon black vertical tank below it and the 2100 gallon black vertical tank above it. The colour and wall swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL at freight class 400 from Norwesco's Washougal, Washington plant as a 90 by 90 by 84 inch load weighing 340 lb. It is bulky rather than heavy; plan a forklift or a few hands to set it down. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 44127 on the bill of lading, look over the base and the outlet fitting for transit damage, and fill with water the first time before the tank carries anything else.
Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
Freight and documents
Ships from: Washougal, WA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44127.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
