A 500 gallon elliptical cradle tank with an inlet and an outlet already fitted
The Norwesco 500 gallon horizontal elliptical cradle tank, part number 40328, is a white polyethylene tank 82 inches long, 57 inches wide and 44 inches tall, weighing 154 lb empty. The elliptical cross section keeps the liquid low and the overall height down, and the smooth underside is shaped to sit in a steel cradle rather than on moulded legs, which is what makes it a trailer and skid tank. It comes with two factory installed 1-1/4 inch polypropylene female NPT bulkhead fittings, one as the inlet and one as the outlet, and a 16 inch threaded vented manway on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 500 gallons of water weighs 4170 lb and the rating allows contents up to 6255 lb. The resin is FDA compliant per Norwesco, the service limit is 120 F, and Norwesco backs the tank with a 3 year warranty.
Is this the right size? Get freight to your ZIP and add it to your cart above, or call 866-418-1777 with the trailer or skid you are putting it on.
On a trailer, a skid or a truck
A cradle tank has no legs of its own, so it needs a cradle or a saddle frame that matches its underside before it can go anywhere. Ask us about the cradle when you order the tank so the two arrive together. At 82 by 57 inches it fits a tandem axle utility trailer or a flatbed, and at 44 inches tall it keeps the load low. Full of water the contents alone weigh close to 4200 lb, and more with fertilizer, so the trailer's axle rating, not the tank, is usually the limit; a pickup bed is the wrong place for this size when it is full. Strap it over the cradle, never over the manway.
What goes in it
Water, liquid fertilizer and the farm and treatment chemicals that polyethylene handles are the normal loads. Before anything new goes in, check the liquid in our chemical compatibility guide; the entries for urea solution, DEF, calcium chloride, sodium hypochlorite and phosphoric acid are the ones cradle tank buyers ask about most. Liquids heavier than 1.5 times water need a heavy duty tank, not this one. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings and fittings
- Outlet. A 1-1/4 inch polypropylene female NPT bulkhead fitting, factory installed. Your valve, pump suction or hose adapter threads straight into it. Support the valve and the first length of hose so the fitting carries liquid, not hardware.
- Inlet. A second 1-1/4 inch polypropylene female NPT bulkhead fitting, so you can plumb a fill line or a return line without drilling the tank. If you do not need it, cap it; a capped spare port is worth having later.
- Manway. A 16 inch threaded vented manway on top: wide enough to fill from a hose or a pump, to drop a float in, and to get a hand and a brush inside to clean.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the exact positions of both fittings and the manway and the profile the cradle has to match.
Sizes nearby
Same tank in yellow, for a high visibility tank on a road crew or a contractor's trailer: the 500 gallon yellow elliptical cradle tank. One size down: the 300 gallon elliptical cradle tank. One size up: the 750 gallon elliptical cradle tank. The colour swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL from the nearest of Norwesco's plants in Fairfield, Texas; Griffin, Georgia; Hanford, California; Lancaster, Ohio; St. Bonifacius, Minnesota; or Tooele, Utah. It travels at 82 by 57 by 44 inches on a pallet and 154 lb, which two people can walk off a liftgate. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 40328 on the bill of lading, look at both fittings and the underside for transit damage, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777, or request a written quote for a job that needs paperwork.
Freight and documents
Ships from: Hanford, CA; Griffin, GA; St. Bonifacius, MN; Lancaster, OH; Fairfield, TX; Tooele, UT. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 40328.
See this tank
Product video. Watch the Norwesco 500 Gallon Horizontal Elliptical Cradle Tank in White video (76 seconds) with dimensions, fittings and shipping notes.
