Snyder Industries 1000 Gallon ASTM HDPE Black Heavy Duty Vertical Storage Tank

The same two plants, a different wall, and the lane that serves both

Buy the lane first and the wall second. This part is molded at Chowchilla, California and at Lincoln, Nebraska, so the western half of the country ships out of the Central Valley and the middle and eastern half ships out of Nebraska, and there is very little of the map that is a genuinely long haul on one or the other. The sheet gives class 300 and 320 pounds shipping weight, so the carrier is not pricing mass at all; it is pricing a parcel 74 inches across, which is over six feet of deck width and the number to check before the requisition is written. Put the destination ZIP into the freight cost estimator and read the listed price as before freight. Then the site, which is where the wide shell earns its keep: 69 inches stands under a roof that a tall 1,000 gallon tank will not clear, and the manway is a short climb rather than a tall one. Load and bearing follow. The 1.9 rating allows 15,846 pounds of contents and plain water alone puts 8,340 pounds inside the shell, and because a rotationally molded floor bears on its whole floor, all of it spreads across the 74 inch circle, which is a gentler pressure per square foot than a narrow tank at the same volume puts down. Pour the slab to the concrete pad sizing guide anyway, level and in full contact and sized to the whole footprint, because a wide tank on a slab with one low corner puts its weight into that corner and stays there. Band it while it is empty even though a low, wide shell is the least wind-sensitive shape here, and look at the bands after the first storm and at the end of the first summer, because a black wall in the sun grows a little every day. Check 1,000 gallons against the draw and the delivery interval in the tank sizing calculator, and take the reserve and the thermal freeboard from the tank sizing guide.

One shell, two wall grades, and the tall 1,000s

The reason to buy this one is that it is the plain high-density wall in the wide shell, so you pay for the footprint, the colour and the rating and not for cross-linking. On a liquid that does not ask for a cross-linked wall, that is the honest specification, and the shell gives up nothing to its stablemate: the cross-linked wall molded in this identical shape is listed separately and shares every dimension, every weight and the same rating, so the two are chosen on chemistry alone. Against the 1831000 tanks in the table, this tank takes back height and spends floor, which is the trade to make when the roof is the binding constraint; each of those is rated as its own sheet says. The 1810000C34 is the slim, very tall smaller tank for an alley, and the 1710000C26 is the widest and lowest tank at the volume above.

Settled on the 1000 gallon tank? Freight to your ZIP and add to cart above; a written quote is one click away for the paperwork.

An eighteen inch manway at the top of a sixty-nine inch shell

• Access before anything else: an 18 inch threaded, vented manway five feet nine inches off the pad, with molded ladder lugs on the shell for the ladder to anchor to. It is a short climb, which is the practical difference between this shell and a tall 1,000 gallon tank, and eighteen inches takes a fill hose, a vent line and a probe together plus a cleaning wand. Nobody enters it; the wand does the inside.
• Outlet: the sheet's outlet field reads "1 Manway / Lid" and lists no bottom fitting size anywhere. That is printed as given, not read as a pipe size. Name the liquid and the draw-off you want at order and we confirm what this molding accepts and in what material before anything is cut.
• Fill and vent: a dip tube to the floor so the stream does not free-fall and foam the headspace, the vent piped outdoors on anything that fumes, sized to the delivery pump rather than the nearest port, and looked at every time the cover comes off.
• Service limit: 120 F / 48 C. Warranty: 3 year. Rating: specific gravity 1.9 as the sheet gives it.

On a high-density wall the part that needs the most attention is the part nobody looks at. The band of shell above the liquid line sits in saturated vapour rather than in liquid, and that is where trouble starts and where a liquid-side inspection never finds it; our article on wall thickness at the vapour-saturated headspace is the one to read before this tank is plumbed, because it explains why that band ages first, why sampling the liquid tells you nothing about it, and what an operator should actually be measuring. Everything else follows the usual discipline: a light on that band each time the cover is off, the thread and gasket seat checked while the light is out, the date on the log, a sender and a local readout because a black wall shows nothing, base plumbing on its own support with a flexible connector to hard pipe, and freeze protection on the piping and the first valve rather than on the body.

Dark bulk storage where the headspace does the ageing

A dense process liquid or concentrate at a plant with a low chemical room, a brine or makeup tank on a wash line, a bulk holding tank on a mixing and dosing skid, a farm or co-op solution that has to stay out of the light, and an outdoor pad in a sunny climate where a pale shell would take the ultraviolet all summer. The wide, low shape is also the one people gang in twos and threes on a single slab, because the roof never becomes the argument. Water at 8.34 pounds per gallon sits far inside the rating, so this tank will hold water perfectly well; a private fire reserve is a different specification in a water-rated vessel. Take the volume and the turnover to the tank sizing calculator before the order, because on a high-density wall a short hold and a full turnover are worth more to the tank than any option you can add to it, and read the tank sizing guide on how much freeboard a warm liquid needs above the working level.

Freight on a seventy-four inch circle

Class 300 and 320 pounds shipping weight, out of Chowchilla, California or Lincoln, Nebraska, is what the sheet gives; tell us the destination and the tank ships from whichever of the two is closer, with the lane priced to your ZIP in the freight cost estimator and the listed price read as before freight. Width is the whole freight story here: 74 inches across is over six feet of deck and it will not nest with other freight, so the parcel is priced on the space and unloaded with a forklift on long forks or a small crane, straps under the body and never a sling through the manway or the ladder lugs. Set it on the cured pad, band it, then fill it with water to the manway and hold it while somebody walks the full circumference of the pad edge twice looking for movement or a weep; drain and dry it before the working liquid arrives. Put the part number on the maintenance log the day it lands, because both walls in this shell look identical from the outside and in five years nobody will remember which one is standing there. Note the pad height and the outlet height on the site plan while the tape is out; the next pipe run will need both.
