10,500 gallons rated for liquids 1.9 times the weight of water
The Snyder 5330300C26 is a white high density linear polyethylene vertical tank, 143 inches in diameter and 177 inches tall, that holds 10,500 gallons and weighs 3,000 pounds empty. The 3,000 pounds is the point: this is Snyder's 1.9 specific gravity wall, which means the tank is built for contents up to 166,383 pounds where the same volume of water weighs 87,570. It is a bulk chemical tank in a water tank's shape, and it also serves as the heaviest-walled water tank Snyder makes at this size.
Want it on your site? Get LTL freight to your ZIP, add it to your cart above, or call 866-418-1777 and a tank specialist will confirm the fit.
Who buys a 1.9 wall at 10,500 gallons
Water plants storing sodium hydroxide, ferric chloride or alum at delivered concentration; industrial sites holding sulfuric acid; anyone whose liquid is denser than water and whose tank must sit outdoors for twenty years. The 10,500 gallon vertical tank buyers guide walks through the class. If the liquid is water, the 1.9 wall still buys something: 3,000 pounds of resin is a thick, stiff shell that shrugs off sun and thermal cycling, at a cost that the tank sizing calculator should justify by volume first.
The 142 to 143 inch family
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 5330300C26 (this tank, 1.9 SG) | 10,500 | 143 x 177 in | 3,000 lb |
| 5330300C37, 1.5 SG | 10,500 | 143 x 177 in | 2,500 lb |
| 5330000C34 | 10,500 | 142 x 169 in | 2,250 lb |
| 5330000N29 | 10,500 | 142 x 169 in | 2,500 lb |
| 32074 | 12,000 | 142 x 197 in | 2,482 lb |
The 5330300C37 is the same mold with a 1.5 specific gravity wall: 500 pounds lighter, rated for a specific gravity of 1.5 instead of 1.9, and the better buy if the liquid is water or a dilute solution. Both share the 3 inch outlet and the 18 inch manway, so the plumbing does not change between them. The 5330000 tanks are 8 inches shorter on a 142 inch base and lighter again. Going the other way, the 32074 adds 1,500 gallons by standing 197 inches tall, which is a water tank's wall and a fire reserve's volume.
Picked the 10500 gallon tank? Add it to your cart above; freight is quoted to your ZIP before you pay anything.
Connections
- Outlet: 3 inch polypropylene female NPT bulkhead fitting at the base, sized for the drawdown a tank this size needs.
- Access: 18 inch threaded, vented manway.
- Service limit: 120 F / 48 C.
Chemical service on a 3 inch outlet means a bolted or flanged transition to hard pipe, an expansion joint, and a valve that the wall does not carry; support the pipe independently. Full, the tank loads the pad to 166,383 pounds at its rating, so the slab is an engineered one. For smaller vessels in the same white 1.9 SG family, the 2,000 gallon vertical tank buyers guide and the 500 gallon vertical tank buyers guide cover the day-tank end of the line.
Water duty
Where the liquid is water, 10,500 gallons is a fire reserve for a commercial site or a small community, and the fire-water reservoir design guide covers NFPA 22 sizing and freeze protection for it. The tank sizing guide converts the volume into days of supply for irrigation or process make-up.
Freight for a 10,500 gallon tank
The 5330300C26 is oversize freight (NMFC 156600) at 143 inches across: a flatbed and a lane rate, which the freight cost estimator prices for your ZIP. The listed price is before freight. Plan a crane or a large telehandler for 3,000 pounds and a slab that is cured. Then water-test in stages, hold the tank full for a day, and walk the outlet, the manway gasket and the slab edge before the product truck is booked; a 1.9 wall does not forgive a pad that settles under 166,383 pounds.
Freight and documents
Ships from: Chowchilla, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5330300C26.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
