10,000 gallons rated to 1.2 specific gravity, in green linear polyethylene
The Snyder 32036 is a 10,000 gallon vertical liquid storage tank, 142 inches across and 166.5 inches tall, in green high density linear polyethylene, 1,816 pounds empty. The number that sets it apart from the water tanks on the same footprint is the rating: 1.2 specific gravity, which means it is molded for liquids up to 1.2 times the weight of water, 100,080 pounds of contents, rather than water alone at 83,400. That headroom is what lets it hold fertilizer solutions, brine and the lighter treatment chemicals that a 1.0 tank cannot take. A 26 inch threaded vented manway on top, 1-1/2 inch polypropylene inlet, 2 inch polypropylene outlet.
Is this the right 10000 gallon tank? Call 866-418-1777 with the liquid, the site and the ceiling height, or get freight to your ZIP and add it to your cart above.
Venting a tank this size is a calculation, not a guess
Ten thousand gallons pumped out fast moves a very large volume of air through the manway vent, and a delivery truck pumping in does the reverse. If the vent cannot keep up, the wall pulls inward on draw-down or bulges on fill, and a 142 inch poly wall does not forgive either. The atmospheric vent capacity guide works the API 2000 inbreathing and outbreathing examples for poly tanks; run it against your pump rate before the tank is set. The HDPE wall thickness at the vapor-saturated headspace article explains why the space above the liquid ages faster than the wetted wall when the tank carries anything but water.
The 10,000 gallon family
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 32463 | 8,000 | 120 x 183 in | 1,547 lb |
| 32034, black | 10,000 | 142 x 166.5 in | 1,816 lb |
| 32036 (this tank) | 10,000 | 142 x 166.5 in | 1,816 lb |
| WB100 | 10,000 | 144 x 161 in | 2,000 lb |
| WG100, green | 10,000 | 144 x 161 in | 2,420 lb |
| WG101, green | 10,500 | 142 x 170 in | 2,490 lb |
Two molds make 10,000 gallons: this 142 inch shape at 166.5 tall, and the 144 inch WB100 and WG100 at 161. The 32034 is this tank in black. The 8,000 gallon 32463 is the one to notice if the pad is tight: 22 inches narrower for 2,000 fewer gallons, but 16.5 inches taller. Buy by footprint first, then by rating, and only then by color.
Comparing across brands too? Call 866-418-1777; we carry Norwesco, Snyder, Chem-Tainer, Enduraplas and Bushman and will say which one fits, or price the freight first.
One hundred thousand pounds on the slab
At the full 1.2 rating this tank puts 100,080 pounds on a 142 inch circle, and the pad is the part of the installation that cannot be fixed later. A reinforced, level slab in full contact with the whole floor is the requirement; the concrete pad sizing guide gives the ACI 360R-10 method. Service limit is 120 F / 48 C. Confirm the volume you need with the tank sizing calculator and the tank sizing guide before the pour, and for chemical duty confirm the liquid against linear polyethylene in the chemical compatibility database.
Where a 1.2 rated 10,000 gallon tank goes
Liquid fertilizer at a co-op, brine at a water plant, the raw water block of a reuse train described in the industrial water reuse topology guide, and, at 1.0 duty, a private fire reserve sized per the fire-water reservoir design guide. The green resin is the conventional choice for a tank in the open that people want to read as clean liquid rather than waste.
Oversize freight
At 142 inches across and 166.5 tall it ships as oversize freight (NMFC 156600) on a flatbed, quoted by lane through the freight cost estimator; the listed price is before freight. Plan the crane or telehandler lift for 1,816 pounds and a 142 inch swing before the truck is dispatched. Fill it in stages the first time, with the vent open and someone watching the pad.
Freight and documents
Ships from: Merced, CA; Albertville, AL. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 32036.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
