The 1.5 specific gravity version of Snyder's 10,500 gallon tank
The Snyder 5330300C37 is a 10,500 gallon white vertical liquid storage tank, 143 inches across and 177 inches tall, molded in high density linear polyethylene with a 1.5 specific gravity wall. It weighs 2,500 pounds empty and is rated for 131,355 pounds of contents, half again the 87,570 pounds that the same volume of water weighs. That makes it the tank for brine, dilute acids and caustics, fertilizer solutions and any liquid that is heavier than water but not the concentrated chemicals that call for the 1.9 wall.
Ready to price it? The listed price is before freight; quote freight to your ZIP in a few seconds, then add to cart above or call 866-418-1777.
1.5 or 1.9: how to decide
Look up the density of what you are storing at the concentration you buy it. Under 1.5, this tank is the right wall and saves 500 pounds of resin against the 5330300C26. Do the arithmetic on the delivered product, not the label: a concentrated caustic solution is far denser than a dilute one, and a tank rated for the dilute product will be overloaded by the concentrate. Over 1.5, or a liquid that will be stored hot or that attacks the resin, step up to the 1.9 wall. The 10,500 gallon vertical tank buyers guide covers the decision at this size; the tank sizing calculator confirms that 10,500 gallons is the volume, not just a big round number.
Related Snyder tanks on a 142 to 143 inch base
| Part | Gallons | Diameter x height | Empty weight |
|---|---|---|---|
| 5330300C37 (this tank, 1.5 SG) | 10,500 | 143 x 177 in | 2,500 lb |
| 5330300C26, 1.9 SG | 10,500 | 143 x 177 in | 3,000 lb |
| 5330000C34 | 10,500 | 142 x 169 in | 2,250 lb |
| 32026 | 10,000 | 142 x 167 in | 2,170 lb |
| 32074 | 12,000 | 142 x 197 in | 2,482 lb |
The 32026 and the 32074 are water tanks: lighter walls at 2,170 and 2,482 pounds, for 10,000 and 12,000 gallons of water, and the 32074 is 20 inches taller than this tank for its extra 1,500 gallons. The 5330000C34 is the 8 inch shorter, 250 pound lighter sibling on a 142 inch base. Between the two 5330300 tanks, the only differences are the 500 pounds of wall and the rating that comes with it.
Want us to check the fit? Send the site dimensions to 866-418-1777 or through a written quote request and we will confirm the tank, the pad and the freight.
Where the pipe goes
- Outlet: 3 inch polypropylene female NPT bulkhead fitting, low on the wall.
- Access: 18 inch threaded, vented manway.
- Service limit: 120 F / 48 C.
Support the outlet piping on its own hangers so the 3 inch bulkhead carries liquid and not pipe weight, and put an expansion joint between the tank and the first hard fitting; a 177 inch polyethylene wall grows and shrinks with the day. The smaller white tanks in this family are covered in the 2,000 gallon vertical tank buyers guide and the 500 gallon vertical tank buyers guide.
Where it serves
Liquid fertilizer and brine at a co-op, dilute treatment chemicals at a plant, and bulk water where a heavier wall is wanted for a long outdoor life. As a water reserve it meets the fire-protection volumes discussed in the fire-water reservoir design guide, and the tank sizing guide puts 10,500 gallons into days of supply.
Freight, in plain terms
A 143 inch diameter makes the 5330300C37 oversize freight (NMFC 156600) on a flatbed, priced by the lane; the freight cost estimator returns that price for your ZIP, and the listed price is before freight. Have lifting equipment for 2,500 pounds and a cured slab ready on delivery day. The first fill is water, in stages, with the outlet and the slab under watch; only after a full hold does the product go in. Where the tank stores fertilizer or brine, plan the fill line and the vent so that foam and off-gas from a fast tanker unload do not push liquid out of the manway.
Freight and documents
Ships from: Chowchilla, CA. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5330300C37.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Ready to order?
Add it to your cart at the top of this page, get LTL freight to your ZIP, request a written quote, or call 866-418-1777. The listed price is before freight.
