Snyder Industries 200 Gallon Rectangular PCO Tank

Where the half inch pays for itself

Nobody buys half an inch for its own sake. What 36.5 inches of width buys is the difference between a tank that drops flat between two wheel arches, two rails or two rack uprights and one that has to be wrestled in at an angle and shimmed. On a bed already fitted with a reel on one side and a locker on the other, the narrowest body in the family is often the only one that goes in flat, and 38.25 inches of height sits under a canopy line or a rack shelf that the taller bodies will not clear. The cost is on the other side of the ledger: at 82 lb it is not the lightest 200 gallon body Snyder makes, so you are paying some payload for the smaller envelope. Set it on continuous, flat support under the full 48 by 36.5 inch base, never spanning two rails with the middle open. Strap over the body, not the lid. A part full rectangular tank moves its load at every stop and the straps hold it; no baffles are listed, so brake early with a full tank and avoid running half full on the road.

What goes in it

Pest control mixes, water and the dilute chemistries polyethylene handles are the normal loads; anything heavier than 1.5 times water needs a higher rated tank. Settle the volume before the shape: run the route, the stops and the refill distance through the tank sizing calculator and take the freeboard and surge allowance from the tank sizing guide. If the tank becomes a fixed fill station on a slab rather than a travelling one, our concrete pad sizing guide covers the pad.

Openings and what to check before you buy

1. Lid. An 8 inch lid on top. It fills from a hose and takes a hand, but it is the smallest opening in this family; if you need to get a brush and a light inside regularly, look at the wider lid bodies linked below.
2. Outlet. None is stated for this part. Tell us the size and position you need before ordering and we will confirm what Snyder supplies.
3. Drawing. Snyder's drawing for this tank is linked under Technical Drawing on this page.
4. Shipping size. The pallet dimensions on this page read 48 by 37 by 40 inches, slightly larger than the tank itself; the tank is 48 by 36.5 by 38.25 inches. Measure against the tank, not the pallet.

Sizes nearby

The three other 200 gallon PCO bodies are each a little wider or taller: the 200 gallon industrial rectangular PCO tank 1660000N43, the 200 gallon portable PCO tank 1660000C137 and the 200 gallon PCO200. Smaller: the 150 gallon industrial rectangular PCO tank. Larger: the 325 gallon white PCO water tank.

Shipping and receiving

The tank ships LTL under NMFC 156600-03 from the nearest of Snyder's plants in Albertville AL or Merced CA, 48 by 37 by 40 inches on the pallet at 82 lb. Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 32149 on the bill of lading, look over every face for transit damage, and fill it with water the first time before it carries a mix.
