Snyder Industries 250 Gallon Plastic Vertical Chemical Storage Tank in White

The day tank with the wide manway

A day tank holds one shift or one day of chemical close to the dosing pump, so a leak is a small one and a wrong fill is caught early. An 18 inch manway on a 36 inch tank is the detail to notice: it admits a fill hose, a float switch and a level sender at once, and a wash-down wand reaches every part of the floor at changeover, which a 6 or 8 inch lid does not allow. The list below is the resin's rated chemistry; check the liquid at its concentration in the chemical compatibility database; the weight rating and the chemical rating are two different questions. The tank sizing calculator turns the pump's rate and the refill schedule into a tank size, and the tank sizing guide covers the reserve a day tank carries. Strap it to a wall; a 36 inch base under 64 inches of dense liquid has a high center of gravity.

Snyder's 210 to 290 gallon chemical tanks

The N42 is the cross-linked twin for hypochlorite and the other oxidizers. On the same 36 inch base, the 1012900C26 is 40 gallons smaller and 9 inches shorter, and the 1013000N45 is 40 gallons bigger and 8 inches taller; the 5740100N42 lays 275 gallons down to 59 inches on a 47 inch base, in cross-linked resin, for under a bench.

Torn between two rows? Call 866-418-1777 with the liquid and the ceiling height, or ask for a quote on both and compare the freight.

Openings, instruments, containment

• Access: 18 inch threaded, vented manway; filled by hose or tote pump through a dip tube, vented outside on anything that fumes.
• Outlet: the bulkhead fitting is chosen for the chemical at order time; a flexible connector to the pump suction, with the valve carried by a bracket rather than the fitting.
• Service limit: 120 F / 48 C.

A white 64 inch tank shows its level in daylight; a low-level float switch keeps the pump from running dry in a pump room, and a sender chosen for the chemical does the rest. Set the dosing pump lower than the outlet so gravity primes it, put a union and a check valve in the suction line, and give the vent a short line routed away from the pump's electrical gear. A 36 inch tank fits a standard spill pallet, which is bought with the tank and emptied if it ever catches anything.

Turnover and changeover

Size the refill schedule so the tank turns over before the chemical degrades; hypochlorite in particular is bought in small lots often, and a day tank that sits for a season wastes chlorine. At changeover the wide manway pays for itself: drain through the outlet, rinse through the manway with a wand, drain again, and let it dry before the new fill, because residue from the last product is the usual cause of a cloudy first batch. Keep the manway closed against vapor loss and the tank out of direct sun where the chemical is light-sensitive, and log each fill with its date and strength.

In service

Hypochlorite and caustic day tanks at small water systems, polymer make-down on a wastewater skid, acid and inhibitor feed at a cooling tower, brine for a softener, and the lab or pilot plant that needs 250 gallons of reagent within reach of a bench. One chemical per tank, labeled.

Freight and unloading

The 1008100N45 ships palletized as LTL freight (NMFC 156600-02) at a class rate; the freight cost estimator shows the lane to your ZIP; the listed figure is the price before freight. One person carries 70 pounds through a door. Strap it, water-fill to the manway and hold it, then drain and dry before the chemical connection is made; mark the vent and the outlet on the shell so nobody caps the wrong one. The first fill is the only cheap time to find a problem, so do it in daylight with someone watching the base.

Rated chemistries for this tank

The manufacturer lists these liquids for this resin at the concentrations noted, with the fitting and gasket material to specify. Check the concentration and temperature you actually run on the linked page or in the chemical compatibility database before ordering.

• Sodium hypochlorite at
• Sulfuric acid at 98% with CPVC fittings and Viton gaskets
• Hydrochloric acid at 37% with PVC fittings and Viton gaskets
• Ferric chloride at 50% with PVC fittings and EPDM gaskets
• Aluminum sulfate at 50% with PVC fittings and EPDM gaskets
• Phosphoric acid at 85% with PVC fittings and Viton gaskets
• Hydrogen peroxide at 50% with PVC fittings and Viton gaskets
• DEF (diesel exhaust fluid) at 32.5% with 316 stainless fittings and EPDM gaskets
• Peracetic acid at 30% with 316 stainless fittings and Aflas gaskets
• Potassium hydroxide at saturated concentration with PVC fittings and EPDM gaskets
