A 500 gallon gravity feed tank system that stands 101 inches tall
The Snyder Industries 500 gallon plastic gravity feed tank system, part number 5780100N97208, is a white high density linear polyethylene tank on its stand, 60 inches long, 66 inches wide and 101 inches tall as a system, weighing 305 lb empty. The opening on top is an 18 inch lid. The tank is rated for liquids up to 1.9 specific gravity with a 120 F service limit. Five hundred gallons of water weighs 4,170 lb, and at the full 1.9 rating the contents can reach 7,923 lb, so the floor under the stand carries that plus the 305 lb of tank. Snyder builds it at Marked Tree, Arkansas.
Feeding a line without a pump? Call 866-418-1777 with the liquid and the ceiling height, or get freight to your ZIP and add it to your cart above.
Why the height is the point
A gravity feed system puts the tank up on a stand so the liquid runs out under its own head, with no pump, no power and nothing to fail at the point of use. That is why it is 101 inches tall for a 500 gallon volume: the stand is doing the work. The height is also the first thing to check against the building. The lid sits at the top of a 101 inch system, so you need ceiling clearance above that to fill and inspect, and a 66 inch wide stand needs a flat, level floor or pad that takes the full load on its feet. Our concrete pad sizing guide for above-ground polyethylene tanks covers the slab under a loaded stand. Snyder files this system with its oil and feed tanks, and the 1.9 rating covers oils, water, fertilizer solutions and the common chemicals polyethylene handles; tell us the liquid when you order and we will confirm the fit.
What to check before you buy
- The outlet. No outlet size is listed for this system. The dispensing point is the whole purpose of a gravity feed tank, so tell us the hose or valve you plan to hang on it and we will confirm what Snyder supplies with the system before it ships.
- The lid. 18 inches. Wide enough to fill from a drum pump or a hose and to see the level without a gauge.
- Head height. The flow you get from a gravity feed depends on how far the liquid surface sits above the point of use; the drawing gives the outlet height so you can plan the run.
- Rating. 1.9 specific gravity and 120 F. Oils and water are well inside it.
- Drawing. Snyder's drawing for the system is linked on this page under Technical Drawing and shows the stand, the outlet position and the overall height.
Related Snyder tanks
If the job is collecting used oil rather than dispensing, Snyder's containment tanks with a level gauge are the better fit: the 405 gallon used oil containment tank, the 500 gallon used oil containment tank and the 750 gallon used oil containment tank. The tank sizing calculator and tank sizing guide cover the volume you need between fills.
Shipping and receiving
The system ships LTL under NMFC 156600-02 from Snyder's Marked Tree, Arkansas plant; the shipping dimensions are listed as 101 by 66 by 60 inches at 305 lb, which means it travels on its side on the trailer and stands up at your site. Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight. Have two people or a forklift ready to stand it up, check 5780100N97208 against the bill of lading, look over the stand legs and the tank bottom for transit damage, and fill it with water the first time to prove the outlet before the real liquid goes in.
Freight and documents
Ships from: Marked Tree, AR. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 5780100N97208.
