Snyder Industries 405 Gallon Used Oil Containment Tank with Level Gauge

Chowchilla to the shop floor, and the pad it lands on

This tank is molded at Chowchilla, California, which makes the western states and the Southwest the short lane and puts a real freight number on a delivery to the east. That matters more than usual here, because the tank is a compact 48 inch square at the base and 73 inches tall, which is six feet one inch: it is an indoor-scale product that a shop will want brought to a specific spot rather than left on a yard, so the route from the truck to the bay is part of the purchase. Measure three things before it is ordered. The doorway, because 73 inches on a pallet is taller than the tank alone and a roller door with a header beam is where these deliveries go wrong. The floor, because 3,378 pounds when it is full of water and 6,418 pounds at the 1.9 rating the sheet gives is standing on a 48 by 48 inch square, which is a high load per square foot on an old shop slab, a mezzanine or a suspended deck. And the space around it, because a used oil tank needs to be reachable for the collection truck's hose as well as for the person filling it, and a tank wedged into a corner makes both jobs worse. Set it on a flat, continuous, level surface across the whole base: finished concrete or a poured pad that carries the plan area, not timber bearers with a span in the middle and not packers under one corner. Where the slab is in question or the tank is going outside, the concrete pad sizing guide for above-ground polyethylene tanks works through the design framework and where a simple slab stops being enough. Size the volume against how often you want the collection truck to call rather than how much oil the shop generates in a year; run it through the tank sizing calculator and take the ullage and freeboard discipline from the tank sizing guide.

The 360, this 405, and the 500 gallon gravity feed system

The choice between the first two rows is a floor plan decision and nothing else. SII-5760102N95704 holds 360 gallons and is described on the sheet the same way this tank is, as a used oil containment tank with a level gauge, but it does it in a 53 by 53 inch square standing 63 inches tall at 234 pounds: wider on the floor and ten inches shorter. This one holds 405 gallons in a tighter 48 by 48 inch square and takes the extra volume upward to 73 inches at 250 pounds. So the reason to buy this one is that it holds more oil in less floor, and the reason to buy the other is a low ceiling or a shelf overhead. In a working bay, floor area is usually the scarcer thing, which is why the taller square tends to win. The third row is a different product and is named as the sheet names it: SII-5780100N97208 is a 500 gallon gravity feed tank system, 60 by 66 by 101 inches at 305 pounds. That is a feed system rather than a waste collection tank, it is substantially bigger in every dimension, and nothing about this page's description applies to it. What none of these three sheets publishes is a stand load, a mounting detail or a burner or heater arrangement, so nothing of that sort is claimed for any of them here.

Found the 405 gallon tank in the table? Freight to your ZIP is one click; add it to your cart above, or call 866-418-1777 to check the grade.

A 2 inch inlet at the top, an 18 inch lid, and no outlet on the sheet

• The way in: a 2 inch inlet, which is the connection a drain line, a funnel station or a pumped return from a bay comes into. Run the line to it with a fall the whole way, support it off the wall or a stand rather than off the tank, and break the last joint with a flexible connector so nothing rigid is loading the polyethylene.
• The lid: an 18 inch opening on top of a tank that stands 73 inches tall, so it is above chest height for most people. That opening is what makes the tank serviceable, but it is also the one that must stay closed in normal use: an open lid on a waste oil tank collects rainwater, shop dust and whatever somebody thought would fit, and a contaminated load is a load the collector may refuse.
• The way out: this sheet publishes no outlet fitting. The collection connection, the pump-out arrangement and any valve are therefore not described here. Tell us how the tank will be emptied and by whom when you order, and the arrangement on your part number is confirmed in writing beforehand.
• The level gauge: it is in the product name, and it is the whole reason a shop buys this version rather than looking in the lid with a torch. Site the tank so the gauge is readable from where people stand, not facing a wall, and check the reading against an actual pump-out at least once so the staff trust it. The level gauge selection guide compares the measuring technologies and where each struggles, which is worth reading before adding any second device.
• Service limit: 120 F / 48 C. Hot drain oil arriving straight off an engine is the one thing a shop routinely puts into a tank without thinking about that number. There is no warranty term on the sheet.

Two habits keep a waste oil tank out of trouble. Label it unmistakably, in words, on the side that faces the door, so nobody tops up a hydraulic reservoir from it and nobody pours coolant or solvent into it. And agree the containment before the first drop goes in: a yellow tank standing on bare concrete in a bay is not containment, whatever colour it is, and the arrangement underneath it should be decided with whoever collects the oil and whoever inspects the site.

Fleet shops, quick lube bays and waste oil collection

Four hundred and five gallons is the size a busy shop fills between collections rather than in a year: truck and bus fleet maintenance shops, quick lube and tyre bays, agricultural and construction equipment dealers, marine yards, municipal vehicle depots, and manufacturing plants collecting used lubricant from machine tools. In all of them the tank is a collection point, so the things that decide whether it works are the drain line to it, the height of the fill connection above the bay floor, the readability of the gauge, and how easily the collection truck can reach it on the day it calls. Get those four right and the tank disappears into the background of the shop for twenty years, which is exactly what you want from it.

Two hundred and fifty pounds, yellow, and the first look at the gauge

The sheet gives Chowchilla, California as the plant, LTL as the freight mode and NMFC 156600, and LTL is a mode rather than a numeric class. It shipments at its own 48 by 48 by 73 inch size on a pallet, so price the lane to your ZIP with the freight cost estimator and note that the listed price is before freight. Two hundred and fifty pounds is a forklift or pallet truck job, taken from beneath the base and never by the lid collar or the inlet. Before the truck is scheduled, walk the route from the dock to the bay with a tape: the door height, the header beam, the aisle turn and the floor along the way. Set it level on the finished floor or pad, connect the inlet line last, then put a few inches of clean water in it and check that the gauge reads sensibly and that the base is bearing all round before any oil arrives. Then record the tank's commissioning date and the collector's contact on the same label as the contents, so that the day it needs emptying nobody is hunting for a phone number. Check the strap tension a week after the first fill; a tank settles a little, and the strap that was tight is loose.
