100 Gallon Plastic Water Storage Tank

Where the tall shape pays off

Buy this shape when floor space is the limit and height is not. At 23 inches across it goes through a door and stands in a corner of a well house, a utility room or a greenhouse, and at 63 inches it puts the water surface more than five feet above the outlet. That head is the point: it floods a pump so it starts against water instead of air, and it runs a gravity line to a trough, a bench or a wash station below the tank without a pump at all. The trade is stability. A tank five feet tall on a two foot base tips easily when it is empty and carries 834 lb of water when it is full, so strap it to a wall or a post before the first fill, and set it on a flat, continuous surface that carries the whole floor. Fill it through the inlet or the lid; at 63 inches the lid is at head height for most people, so put the level gauge or sight line where you can read it from the ground. Check the volume against your draw with the tank sizing calculator and the reserve rules in the tank sizing guide. Where the tank is one stage of a rainwater or grey water train, our water reuse tank topology guide covers how the stages are sequenced; for a rural fire reserve, the fire water reservoir design guide explains why 100 gallons is a component rather than the reservoir.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. A 2 inch valve, camlock or hose adapter threads straight in, and a 2 inch drain empties the tank quickly. Support the valve and the first length of hose so the fitting carries water, not hardware.
2. Inlet. A 1-1/2 inch polypropylene female NPT bulkhead fitting for the fill line or the overflow. Run an overflow to daylight away from the base.
3. Lid. An 8 inch lid on top: large enough to fill from a hose, drop a float in and look inside, not large enough to reach in and scrub, so clean through the openings or with a wand.
4. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the fitting positions and the lid location.

Sizes nearby

One size down on the same 23 inch diameter is the 75 gallon vertical water tank, shorter and with smaller fittings. If you have floor but not height, the 120 gallon dark green tank holds more water on a wide, low shell. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL from Norwesco's Burnet, Texas plant, 23 by 23 by 63 inches on a pallet at a ship weight of 50 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or request a written quote. It needs a flat, level, continuous surface under the whole 23 inch floor; for an outdoor base the concrete pad sizing guide has the framework. At the tailgate, check the part number against 41464 on the bill of lading and look at the wall and both fittings for transit damage. Fill it with water the first time, strapped, and watch the fittings for a day before it goes into service; the water fill acceptance test guide gives the method.

Questions before you order? Call 866-418-1777.
