A 10000 gallon 30 degree cone bottom tank, the largest cone in the line
The Norwesco 10000 gallon 30 degree cone bottom tank, part number 44103, is a white polyethylene tank 141 inches in diameter and 190 inches tall, weighing 2156 lb empty. The 30 degree cone bottom sends the whole load to the outlet at the point of the cone, so settled material slides out with the liquid and the tank empties without a pump or a scrape. It comes with a 3 inch polypropylene female NPT bulkhead fitting at the cone outlet and a 16 inch threaded vented manway on top. The tank is rated for liquids up to 1.5 specific gravity, which covers water, most liquid fertilizers and many common chemicals; 10000 gallons of water weighs 83400 lb. The resin is FDA compliant per Norwesco, the service limit is 120 F, and Norwesco backs it with a 3 year warranty. A cone bottom tank needs a stand: Norwesco pairs this one with stand N-64070, sold separately.
Specifying bulk storage at this scale? Call 866-418-1777 and we will go through the tank, the stand, the fittings and the delivery with you, or get freight to your ZIP and add it to your cart above.
Where this tank goes
Ten thousand gallons in a cone bottom is a plant tank: fertilizer terminals and large dealers, water and wastewater chemical storage, food and process plants that batch and need the vessel empty between runs. It shares its 141 inch diameter and its stand with the 7500 gallon tank in the same line, so the extra capacity comes from height, 190 inches of it before the stand goes underneath. That makes it an outdoor tank or a high-bay tank; settle the slab, the route in and the lifting plan before you order. The 30 degree cone is steep enough that settled solids slide to the outlet instead of ledging on the slope. Our cone bottom buyers guide comparing 15, 30 and 45 degree cones explains the angle choice, and the 10000 gallon 30 degree cone bottom buyers guide covers this tank in detail. For the volume itself, use the tank sizing calculator and tank sizing guide.
What goes in it
Water, liquid fertilizer and the industrial and treatment chemicals that polyethylene handles. Check the liquid in our chemical compatibility guide before the first fill; the entries for urea solution, sulfuric acid, sodium hypochlorite, ferric chloride and phosphoric acid are the ones cone bottom buyers ask about most. The 1.5 rating means a liquid up to 1.5 times the weight of water, 12.52 lb per gallon. Heavier liquids belong in the heavy duty version, the 10000 gallon 30 degree cone bottom tank in light blue, rated to 1.9. Keep the contents under 120 F.
Openings, fittings and the stand
- Outlet. A 3 inch polypropylene female NPT bulkhead fitting at the point of the cone. Thread the valve in before the tank is set, and support the pipe run on its own so the fitting carries liquid and not the weight of a valve and hose.
- Manway. A 16 inch threaded vented manway on top. At this height, plan a fixed fill line and a level gauge so routine fills never need a climb to the manway.
- Stand. Stand N-64070 is required and sold separately. Tank, stand and 83400 lb of water is a load the slab has to be designed for; your installer and Norwesco's documentation set that, not this page.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the cone geometry, the outlet position and the overall height with the manway.
Sizes nearby
Same capacity with a shallower cone: the 10000 gallon 15 degree cone bottom tank in black and the 10000 gallon 15 degree cone bottom tank. One size down on the same footprint and stand: the 7500 gallon 30 degree cone bottom tank. The swatches above the price switch between the white and heavy duty versions of this tank.
Shipping and receiving
This is an oversize load. It ships by flatbed or dedicated truck from the nearest of Norwesco's plants in Fairfield, Texas and St. Bonifacius, Minnesota, 190 by 141 by 141 inches lying down and 2156 lb. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, and a written quote is available for a job that needs paperwork. Standing this tank up takes a crane or a large loader with wide straps around the cylinder, never a chain around the cone or a strap through the manway; have the equipment and the crew on site before the truck. At the tailgate, check the part number against 44103 on the bill of lading, look over the cone, the outlet fitting and the manway for transit damage, set the tank in its stand on a level floor, and fill it with water the first time before it carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: St. Bonifacius, MN; Fairfield, TX. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44103.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 10000 Gallon 30 Degree Cone Bottom Tank video (72 seconds) with dimensions, fittings and shipping notes.
