A 7500 gallon black cone bottom tank for process and bulk storage
The Norwesco 7500 gallon black cone bottom tank, part number 42976, is a polyethylene process and storage tank 141 inches in diameter and 149 inches tall, weighing 1385 lb empty. This is the 30 degree cone version of the shell; the white and blue versions of the same tank are listed below. The cone bottom lets the whole contents drain to the 3 inch outlet at the low point, so nothing is left behind to settle or contaminate the next batch, and a 30 degree cone moves solids and heavier liquids along better than a shallow one. It has a 16 inch lid on top. Norwesco rates it for liquids up to 1.5 specific gravity; 7500 gallons of water weighs 62550 lb. The resin is FDA compliant per Norwesco and the service limit is 120 F. Black keeps light out of the contents. The tank needs a stand, Norwesco part N-64070, which is sold separately.
Ordering the tank and the stand together? Request a written quote or call 866-418-1777 and we put both on one order so they arrive together.
Where it goes
At 7500 gallons this is a plant-scale vessel: a blend tank at a fertilizer dealer, or a settling or process tank at a treatment site. The cone sits in a stand, and the stand needs a flat, level, continuous slab under all its feet. A full tank on a raised stand is a concentrated load; the floor loading comes from the tank and stand documentation and your engineer, not this page. Plan the fill line, the vent and the level gauge from the ground, since the lid is well above head height in the stand; our write-up on top fitting placement, vent and fill layout and the operator errors bad layout causes covers the decisions. The complete buyers guide to the 7500 gallon cone bottom walks through this shell end to end, and the guide to choosing between the shallow, medium and steep cone angles explains when the 30 degree cone is the right middle choice.
What goes in it
Water, liquid fertilizer, brine and the treatment and process chemicals polyethylene handles. Before anything goes in, check the liquid in our chemical compatibility guide; the entries for sodium hypochlorite, sulfuric acid, hydrochloric acid, calcium chloride and urea solution are the ones cone tank buyers ask about most. Liquids heavier than 1.5 times water need the heavy duty version: the 7500 gallon 30 degree cone bottom tank in blue is the same shell rated to 1.9. For the volume itself, use the tank sizing calculator and tank sizing guide.
Openings, fittings and the stand
- Outlet. 3 inch at the bottom of the cone. Fit a valve directly to it so the tank can be shut while the line below is worked on, and support the valve and the first length of pipe on their own so the cone carries liquid, not hardware.
- Lid. 16 inches on top: fill from a hose or a pump, drop a float or a level sender in, and get a hand and a brush inside.
- Stand. Norwesco pairs this tank with stand N-64070, sold separately. A 30 degree cone sits in a 30 degree stand of the right diameter and nothing else; the stand compatibility matrix across Norwesco, Snyder and Enduraplas shows why the pairing is fixed.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the cone, the outlet and the lid positions.
Same tank, other colours and ratings, and sizes nearby
This shell comes three ways: black, as here; white, the 7500 gallon 30 degree cone bottom tank in white, for liquids where you want to see the level through the wall; and blue heavy duty, the 7500 gallon 30 degree cone bottom tank in blue, rated to 1.9. The swatches above the price switch between them. One size down with a shallower cone is the 6000 gallon 15 degree cone bottom tank in black; one size up is the ten thousand gallon 30 degree cone bottom tank in black.
Shipping and receiving
The tank ships as oversize freight, 149 by 141 by 141 inches and 1385 lb, from the nearest of Norwesco's Shawnee, Oklahoma, St. Bonifacius, Minnesota and Washington Court House, Ohio plants. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. Plan the unloading and the lift into the stand before the truck arrives: a tank this wide needs a loader or a crane and slings, and the driver will not do it alone. At the tailgate, check the part number against 42976 on the bill of lading, look at the cone tip and the outlet for transit damage, set the stand level across both diagonals before the tank goes in, and fill with water the first time so any problem shows with something harmless in the tank.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: St. Bonifacius, MN; Washington Court House, OH; Shawnee, OK. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 42976.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the Norwesco 7500 Gallon Black Cone Bottom Tank video (72 seconds) with dimensions, fittings and shipping notes.
