A 330 gallon cross-linked polyethylene vertical tank for day tanks and chemical feed
Snyder part number 1011600N42 is a 330 gallon vertical storage tank in white cross-linked polyethylene, 44 inches in diameter and 58 inches tall, 80 lb empty, made at Snyder's Philippi, West Virginia plant. It is rated for liquids up to 1.9 specific gravity: 330 gallons of water weighs 2,752 lb (330 x 8.34), and a liquid at the full rating about 5,229 lb. The top is an 18 inch threaded vented manway. Snyder lists it as an ASTM tank. If an inspector or a drinking water permit needs the paper, ask us and we will get Snyder's documents for this part number.
Replacing a day tank? Call 866-418-1777 with the old tank's size and the liquid, or get freight to your ZIP and add it to your cart above.
What a 330 gallon cross-linked tank is for
At 44 inches across and under five feet tall, this is a tank that fits inside a pump room, a treatment building or a containment curb next to the equipment it feeds. Cross-linked polyethylene is the wall people choose for heavier liquids and for service where the tank is filled and drawn down day after day: chlorination and coagulant feed at a water plant, a process makeup tank, a rinse or wash water reserve. Check the liquid in our chemical compatibility guide before you order and name it on the order. Our guide to wall thickness at the headspace explains where polyethylene tanks wear and why. For water and reuse service, see the water reuse tank layout guide and the rural fire water reservoir guide. Full, up to 5,229 lb rests on a 44 inch circle; set it on a level surface that carries the whole floor, per the concrete pad sizing guide.
What to check before you buy
- Outlets. No outlet size is listed for 1011600N42. Tell us the size and position you need and we will confirm with Snyder what comes on the tank and what can be added.
- Manway. 18 inch threaded and vented: room for a fill line, a mixer or a level transmitter.
- Temperature. No temperature limit is listed. Tell us if the liquid goes in warm.
- Drawing. Snyder's drawing is linked under Technical Drawing on this page.
Sizes nearby
Other 330 gallon Snyder tanks: the 330 gallon ASTM XLPE heavy duty tank 1008200N42, the 330 gallon heavy duty tank 1008200C26 and the black version 1008200C34. One size down, the 300 gallon heavy duty tank; one size up, the 360 gallon ASTM XLPE heavy duty tank. Check the volume in the tank sizing calculator and the tank sizing guide.
Shipping and receiving
It ships from Philippi, West Virginia at 80 lb, shipping size 44 by 44 by 58 inches. The listed price is before freight; the freight cost estimator gives the cost to your ZIP. Check 1011600N42 on the bill of lading, look the shell over before you sign, and fill it with water once before the working liquid goes in.
Ready to order? Add it to your cart at the top of this page, get LTL freight to your ZIP, or call 866-418-1777. The listed price is before freight.
Freight and documents
Ships from: Philippi, WV. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Snyder Industries 1011600N42.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
Product video. Watch the 330 Gallon XLPE Vertical Liquid Storage Tank with ASTM Certification video (65 seconds) with dimensions, fittings and shipping notes.
