65 Gallon Vertical Liquid Storage Tank

Where a 23 inch tank earns its place

This is the size for a spot where a drum would be the alternative: a corner of a shop, the deck of a small dosing or wash-down skid, a well house, a utility room, a greenhouse bench or the back of a service truck. At 23 inches across it fits through any doorway upright and sits on half a pallet position. At 43 inches tall the lid is at waist height, so you can fill it from a hose or a bucket without a step. Full of water it puts about 540 lb on a 23 inch circle, so it wants a flat, continuous surface under the whole base: a slab, a solid deck or plywood over joists, never a grate or a pair of bearers with a gap between. Our guide to concrete pad sizing for above ground polyethylene tanks covers what the surface under a tank needs to do when the tank is outdoors.

What goes in it

Potable and non-potable water, liquid fertilizer, wash water and the common treatment chemicals that polyethylene handles are the normal loads at this size. Anything heavier than 1.5 times the weight of water needs the heavy duty version of a tank, not this one; our note on the 75 gallon heavy duty vertical tank is the next step up in rating. Keep the contents below 120 F; hot process water and fresh fertilizer blends that are still warm both count. If the tank is part of a fire water supply on a rural site, our guide to fire water reservoir design for rural and remote sites explains where a polyethylene tank fits and how to keep it from freezing. For the volume itself, the tank sizing calculator and the tank sizing guide turn a daily draw into a tank size.

Openings and fittings

1. Outlet. A 1-1/4 inch polypropylene female NPT bulkhead fitting, factory installed low in the side wall. A 1-1/4 inch ball valve or a hose adapter threads straight in. Dry-fit the valve so the handle swings clear of the tank before you seal the threads, and support the first length of pipe or hose on its own so the fitting carries liquid, not hardware.
2. Lid. An 8 inch threaded vented lid on top. It is wide enough for a hose, a float switch or a small pump inlet, and the vent lets air in as the tank drains so the walls are never pulled inward.
3. Drawing. Norwesco's drawing for this tank is linked on this page under Technical Drawing. It gives the outlet height and the lid position for planning the pipe run.

Sizes nearby

Same tank in black, for water you want to keep algae out of: the 65 gallon black vertical storage tank. One size down: the 55 gallon vertical liquid storage tank. For heavier liquids at nearly the same footprint: the 75 gallon heavy duty vertical tank, rated 1.9. The colour swatches above the price switch between the versions of this tank.

Shipping and receiving

The tank ships LTL from the nearest of Norwesco's plants, 23 by 23 by 43 inches on a pallet at a ship weight of 50 lb. Norwesco makes this tank at Burnet and Fairfield in Texas, Griffin, Georgia, Hanford, California, Lancaster, Ohio, Owego, New York, Shawnee, Oklahoma, Sheldon, Iowa, St. Bonifacius, Minnesota, Tooele, Utah and Washougal, Washington, so most of the country has a short lane. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number 45192 against the bill of lading, look over the base and the outlet fitting for transit damage, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777 or request a written quote.
