750 Gallon Doorway Water Tank

Where 750 gallons goes through a door

This is the tank for a basement, a barn, a pump house or a shop that needs serious water storage behind an ordinary door: a well holding tank where the well recovers slowly, a fire reserve at a rural property, a rainwater store under a large roof, a process water tank in a building that was never going to take a round tank. It stands 85 inches, just over seven feet, so measure the ceiling and the door header as well as the door width. Full, it is 6255 lb of water standing on an 82 by 35 inch rectangle, carried entirely by the moulded base, which is why the pad is the install: level, continuous, in full contact, with no drain, joint or lip under the footprint. Our concrete pad sizing guide for above ground polyethylene tanks gives the method. The 750 gallon doorway tank buyer's guide goes through the common installs, the fire water reservoir design guide covers a rural fire reserve, and the water reuse tank guide covers rainwater and grey water systems.

What goes in it

Water is the normal load, and the white wall lets you see the level through it in good light. The 1.5 specific gravity rating, a maximum of 12.52 lb per gallon, means it will also hold most liquid fertilizers and the common solutions polyethylene handles. Keep the contents under 120 F. For drinking water, keep the manway closed and the tank out of direct sun; light grows algae in standing water. To check that 750 gallons is the right reserve, run your daily draw and your refill interval through the tank sizing calculator and take the freeboard from the tank sizing guide.

Openings and fittings

1. Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. A 2 inch valve, a camlock or a pump suction threads straight into it, and 2 inches drains or feeds a pump much faster than the smaller port on the small doorway tanks. Support the valve and the first length of pipe on its own so the fitting carries water, not hardware.
2. Manway. A 16 inch threaded vented manway on top: wide enough to fill from a hose or a pump, to drop a float switch in, and to get an arm and a brush inside to clean. The vent lets air in as the tank drains, so never seal it.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, gives the exact outlet and manway positions.

Sizes nearby

One size down, lighter and easier to move: the 500 gallon doorway water tank. One size up: the 1000 gallon doorway water tank, which is wider than a standard door and needs a double door or a wide opening. That is the reason to buy the 750 rather than the next size: it is the largest doorway tank that still goes where the small ones go.

Shipping and receiving

The tank ships LTL on a pallet, 82 by 35 by 85 inches and 409 lb packed, from the nearest of Norwesco's plants in Lancaster, Ohio, Shawnee, Oklahoma and St. Bonifacius, Minnesota. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At 325 lb empty, moving it is a job for four people or a machine, not two, so plan the path from the truck to the door before delivery day. At the tailgate, check the part number 44310 against the bill of lading, look over the wall and the fitting for transit damage, and fill it with water the first time before it carries anything else.

Questions before you order? Call 866-418-1777.
