A 1505 gallon light blue heavy duty vertical tank on a five foot base
The Norwesco 1505 gallon light blue heavy duty vertical storage tank, part number 44261, is a rotomolded polyethylene tank 60 inches in diameter and 135 inches tall, weighing 340 lb empty. It is a tall, narrow tank: eleven feet three to the crown on a base exactly five feet across, which puts 1505 gallons where a wider tank would not go. The wall is Norwesco's heavy duty grade, rated for liquids up to 1.9 specific gravity, which takes in water, every common liquid fertilizer and most of the chemical solutions polyethylene handles; 1505 gallons of water weighs 12552 lb, and at the full 1.9 rating the contents can reach 23848 lb. It comes with a 2 inch polypropylene female NPT bulkhead fitting as the outlet and a 16 inch threaded vented manway on top. The resin is FDA compliant per Norwesco, Norwesco lists the tank as NSF 61, the service limit is 120 F, and Norwesco backs the heavy duty tank with a 5 year warranty. Light blue absorbs less of the sun's heat than black, which keeps the contents cooler on an exposed pad.
Have the height for it? Call 866-418-1777 with the clear height and the liquid, get freight to your ZIP and add it to your cart above, or request a written quote.
Where it goes and what it holds
This is the tank for a narrow slot with sky above it: beside a greenhouse wall, in the corner of a pump house, between two buildings, or in a fenced chemical yard where every square foot is spoken for. The heavy duty wall makes it a fertilizer or chemical feed tank rather than a plain water tank; liquids denser than water put more stress on the wall near the base, and the 1.9 rating is built for that. For plain water the standard wall tank in the same mould costs less. Check the liquid in our chemical compatibility guide before the first fill and keep it under 120 F. The height is the thing to plan around: the manway sits at the top of 135 inches, so filling, float valve service and cleaning need a ladder or a platform. A tall narrow tank is also the least forgiving of a poor pad, because a high spot under one edge becomes a lean you can see from across the yard; the pad has to be flat, continuous and level under the whole 60 inch base, and our guide to concrete pad sizing for above ground polyethylene tanks sets out the slab. The tank sizing calculator and tank sizing guide settle the volume.
Openings and fittings
- Outlet. A 2 inch polypropylene female NPT bulkhead fitting, factory installed low in the wall. Your valve, camlock or pump suction threads straight in. On a tank this tall the head at the outlet is higher than on a squat tank of the same volume, so support the valve and the first length of pipe on their own within a foot of the wall and put a flexible connector before the first rigid joint.
- Manway. A 16 inch threaded vented manway on top: fill from a hose, drop a float or a level sensor in, and get a hand and a brush inside to clean. Leave the vent clear so air can move as the level changes.
- Extra ports. Only the one outlet comes installed. A recirculation return, a second draw or an overflow means extra bulkhead fittings; tell us when you order and we quote them with the tank.
- Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height, the manway position and the base profile.
Sizes nearby
The same heavy duty wall in black, which keeps light out of the contents and slows algae, is the 1505 gallon black heavy duty vertical tank. The standard 1.5 wall in this mould comes as the 1505 gallon black vertical tank or in white as the 1500 gallon white vertical tank. Nearby sizes: the 1500 gallon black vertical tank, a different mould, and the 1550 gallon black vertical tank; compare their diameters and heights on their pages against your slot. The colour and wall swatches above the price switch between the versions of this tank.
Shipping and receiving
The tank ships LTL at freight class 300 from Norwesco's Fairfield, Texas plant as a 60 by 60 by 135 inch load weighing 340 lb. Two people can walk it off a liftgate and roll it on its base to the pad; it is the height that makes it awkward, not the weight. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP. At the tailgate, check the part number against 44261 on the bill of lading, look over the base and the outlet fitting for transit damage, and fill with water the first time before the tank carries anything else.
Questions before you order? Call 866-418-1777.
Freight and documents
Ships from: Fairfield, TX. LTL freight is quoted to your ZIP with the freight cost estimator or by phone at 866-418-1777. The listed price is before freight.
Technical drawing (PDF) for Norwesco 44261.
See this tank
Interactive 3D model with live fill. This tank has an interactive 3D model built to its manufacturer dimensions. Rotate it, and set a fill level to see how much liquid it holds at any height. Open the 3D view on the product photo above. Download the 3D model (GLB).
