1505 Gallon Vertical Liquid Storage Tank

Where a tall, narrow 1500 fits

Buy this shape when the floor is spoken for and the air above it is not: against the wall of a shop or a packing shed, in a row of tanks along a fence line, in a corner where a wider tank will not go. Check the height first. At 135 inches the top of the tank is over eleven feet up, which rules out most eaves and many barn bays, and the lid is up there with it, so plan a fill line plumbed to the top and fit the float switch or level gauge before the tank goes into service. The 60 inch base needs a flat, level, continuous surface; because it carries 18828 lb at full rating on a five foot circle, a concrete pad is the right foundation. Our concrete pad sizing guide covers how to size the slab. A tank this tall on this base must be strapped or anchored where wind is a factor, and kept strapped while empty. The complete buyers guide to this tank goes deeper.

What goes in it

Water, rainwater, liquid fertilizer and the common farm and treatment chemicals that polyethylene handles are the normal loads. Keep the contents below 120 F and below 1.5 times the weight of water. Heavier liquids belong in the heavy duty version of this same shell, rated to 1.9 specific gravity, which Norwesco makes in blue and in black; the options above the price list them. For a rural fire reserve, the fire-water reservoir design guide explains where a polyethylene tank sits in a private fire protection stack. For grey water and rainwater collection, the industrial water reuse topology guide covers arranging several tanks by water quality. Size the volume with the tank sizing calculator or the tank sizing guide.

Openings and fittings

1. Outlet. A 2 inch outlet low in the side wall. Tell us the connection you are making and we confirm the fitting type and thread on the tank that ships to you. Whatever the fitting, turn the tank so the outlet faces the pipe run before the first fill, and support the valve and the first length of pipe on their own so the fitting carries liquid, not hardware.
2. Lid. A 16 inch lid on top, wide enough to fill from a hose or a pump, to drop a float in and to get a brush inside. Confirm with us whether you need it vented for your fill and draw arrangement.
3. Drawing. Norwesco's drawing for this tank, linked under Technical Drawing on this page, shows the outlet height and the lid position for pipe planning.

The same shell in other versions

Same shell in black, for water that will stand a long time: the 1505 gallon black vertical tank, 44259B; the colour swatches above the price switch between them. For denser liquids, the 1505 gallon light blue heavy duty tank, 44261 and the 1505 gallon black heavy duty tank, 44261B are the same shell with a heavier wall.

Shipping and receiving

The tank ships by LTL freight at freight class 400, lying down on the trailer at 135 by 60 by 60 inches with a ship weight of 285 lb, from Norwesco's Fairfield, Texas plant. The listed price is before freight; the freight cost estimator gives the lane cost to your ZIP, or ask for a quote for a job that needs paperwork. Three people, or a loader with a strap, stand it up at delivery; have the pad ready so it goes straight to its spot. At the tailgate, check the part number against 44259 on the bill of lading, look over the full length of the shell for transit damage before signing, and fill it with water the first time so any problem shows up with something harmless inside.

Questions before you order? Call 866-418-1777.
